Quick Details
Description
- Condition: New
- CNC or Not: CNC
- Power Source: Hydraulic
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: DYMG
- Model Number: YD34
- Voltage: 220V/380V/415V(According required )
- Power(W): 11KW-400KW
- Weight: 6ton-300ton
- Dimension(L*W*H): about -15500mmx9500mmx12500mm
- Certification: CE ISO
- Warranty: 12 Months
- After-sales Service Provided: Engineers available to service machinery overseas
- Product name: YD34 H Framework Hydraulic Press(100ton~6000ton)
- Keyword: Hydraulic Press
- Structure: Three-beam four-post type
- Feature: pressure and the stroke can be adjustable within the specified range.
- Technology Process: fixed pressure and fixed stroke forming process
- Control: integrated control
- Optional 1: Moveable Bolster,Punching buffering device
- Optional 2: Industrial Touch Display
- Application: metal material drawing, blanking (equip with buffer device)
- Color: Customizable
|
Item
|
Unit
|
YD34-
100
|
YD34-
200
|
YD34-
315
|
YD34-
500
|
YD34-
1000
|
YD34-
3000
|
YD34-
6000
|
|
Rated Force
|
KN
|
1000
|
2000
|
3150
|
5000
|
10000
|
30000
|
60000
|
|
Ejection Force
|
KN
|
800
|
—
|
400
|
—
|
1000
|
2000
|
—
|
|
Slide Stroke
|
mm
|
800
|
710
|
800
|
900
|
900
|
2500
|
2000
|
|
Ejection Stroke
|
mm
|
350
|
—
|
250
|
—
|
350
|
350
|
—
|
|
Open Height
|
mm
|
1100
|
1100
|
1200
|
1500
|
1500
|
3500
|
4000
|
|
Slider Speed
|
Free Stroke
|
mm/s
|
150
|
200
|
150
|
180
|
250
|
200
|
150
|
|
Work
|
mm/s
|
8-15
|
8-18
|
8-15
|
8-16
|
8-20
|
5-10
|
6-12
|
|
Return
|
mm
|
100
|
150
|
140
|
160
|
200
|
150
|
120
|
|
Ejection Speed
|
Ascend
|
mm
|
70
|
—
|
100
|
—
|
80
|
100
|
—
|
|
Return
|
mm
|
140
|
—
|
150
|
—
|
220
|
200
|
—
|
|
Bolster Size
|
L-R
|
mm
|
1200
|
1100
|
1500
|
2200
|
2000
|
4000
|
5000
|
|
F-B
|
mm
|
1200
|
900
|
1200
|
1500
|
1400
|
3000
|
4000
|
|
Main Motor
|
KW
|
11
|
22
|
22
|
45
|
91
|
150
|
400
|
Product Features:
* The machine framework adopts the computer optimization design, the whole welded frame structure, ensure high accuracy.
* Hydraulic control adopt cartridge valve integrated system, ensure reliable work, large flow, smaller leakage, long service of life and highly centralized system, reduce connected pipes and leakage.
* Adopt centralized control buttons, with adjustment, manual and semi-automatic (fixed stroke and fixed pressure) three kinds of operating mode.
* Four corners and eight side guide rails, high precision of guidance , strong resistance of eccentric load.
* High slider speed ensure high work efficiency.
* Slider working pressure, no-load fast descending ,and slow speed of working , are all can be adjustable according to the technology.
XUZHOU DAYI INTELLIGNE TECHNOLOGY CO.,LTD
is a large-scale professional power press R&D and manufacturing enterprise, covered capacity 40ton~18000ton .
* Inherited more than 60 years of metalforming R&D and Manufacturing experiences, more than 20 patents.
* Factory Area 200,000.00 square meters.
Main Products :
* Hydraulic Press
*Forging Hydraulic Press
* Special Purpose Customized Power Press.
Widely used in varieties of areas of aerospace, automobile manufacturing, shipbuilding, home appliances and others ,popular for technologies of drawing, blanking, bending, Extrusion, Forging, SMG Composite molding , and etc.
Technology advantages :
* Take lead in technologies of proportional servo control, position digital control, synchronizing control, screen-touching and industry computer control, adopt three-dimension and module design technology, representing the highest level in the hydraulic press industry in china
Manufacturing Strength:
*The company have lots of large floor boring and milling machines, heavy lathes, milling machine planers and other key equipments, for varieties of machining.
*Also established new production base specially for heavy duty hydraulic press manufacturing more than 4000ton.
Marketing :
* As a result of good quality and reputation so that our products renowned at home and abroad, typical customers such as China CRRC ,China CSR,China FAW ,YTO,SINOPEC,CSIC,SHIFENG GROUP ,LIFAN AUTO, BTE wheel , SUNRISE Wheel , Fiat, Bosch,Gree Air-conditioners, and etc.
*The presses already exported to over 20 countries and regions, such as Asia, Australia, America and Africa, and etc.
