Quick Details
Description
- Condition:New
- Place of Origin:Henan, China (Mainland)
- Brand Name:OEM
- Model Number:WC67K
- Machine Type:Press Brake
- Raw Material:Sheet / Plate Rolling
- Material / Metal Processed:Carbon Steel
- Power:Cnc
- Automation:Automatic
- Extra Services:End Forming
- Certification:CE
- After-sales Service Provided:Engineers available to service machinery overseas
- Nominal pressure:80kn
- Length of table:3200mm
- Height of table:900mm
- Distance Between Housing:2600mm
- Slide Stroke:200mm
- Die Set height:480mm
- Throat Depth:380mm
- Number of the CNC axes:3+1 axis
- Slide repeat positioning accuracy:0.01mm
- main power:11kw
Characteristics of our laser cutting machine
Application of WC67Y hydraulic cnc press brake machinery price
This WC67K CNC Hydraulic press brake and metal bending machine can bend metal sheet material with higher labor productivity and working accuracy, the upper die and the lower die adopts different shape, which can fold different shape of the workpiece, the slide block can be carried out to bend,complex shape workpiece will be achieved after several bending, when equipped with appropriate equipment, can do with a punching.
Performance and characteristics:
all steel welded structure, sufficient strength and rigidity,
hydraulic upper drive block synchronous mechanism adopts torsion shaft forcing and mechanical block,stable and reliable wedge type deflection compensation structure
Slide stroke is quickly adjusted with manual adjustment and counter display
Backguage adopts mechanical quick regulation, manual fine tuning and counter display;
Technical parameters
|
No.
|
Description
|
Parameter
|
Unit
|
|
1
|
Nominal Pressure (KN)
|
1250
|
KN
|
|
2
|
Length of table (mm)
|
3200
|
mm
|
|
3
|
Height of table (mm)
|
900
|
mm
|
|
4
|
Distance Between Housing (mm)
|
2600
|
mm
|
|
5
|
Slide Stroke(mm)
|
200
|
mm
|
|
6
|
Die Set height
|
480
|
mm
|
|
7
|
Throat Depth (mm)
|
380
|
mm
|
|
8
|
Number of the CNC axes
|
3+1 axis(Y1,Y2,X,V)
|
axis
|
|
9
|
Slide running speed
|
Approach Speed
|
110
|
mm/s
|
|
Working
|
9
|
mm/s
|
|
Return stroke
|
110
|
mm/s
|
|
10
|
Slide repeat positioning accuracy
|
0.01
|
mm
|
|
11
|
Backgauge X axis
|
Stroke
|
0-850
|
mm
|
|
Gauge range
|
600
|
mm
|
|
Max running speed
|
300
|
mm/s
|
|
Max positioning accuracy
|
0.05
|
mm
|
|
12
|
Overall dimensions
|
Length
|
3300
|
mm
|
|
Width
|
1600
|
mm
|
|
Height
|
2900
|
mm
|
|
13
|
Main motor power
|
11
|
Kw
|
|
14
|
Weight
|
12
|
T
|
