Quick Details
Description
- Condition:New
- Laser Type:Fiber Laser
- Applicable Material:Metal
- Cutting Thickness:0-30mm
- Cutting Area:2000*4000mm
- Cutting Speed:60-120m/min
- CNC or Not:Yes
- Cooling Mode:Water Cooling
- Control Software:Cypcut/Beckhoff/ PA8000
- Graphic Format Supported:AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
- Place of Origin:Henan, China (Mainland)
- Brand Name:BAIWEI
- Model Number:BW-G3015
- Certification:CE
- After-sales Service Provided:Engineers available to service machinery overseas
- Laser power:500w 1000w 2000w 3000w Fiber laser
- Warranty:2 Years
- Laser Head:Swiss Raytools/ America lasemech
- Driving System:Japan Servo motors
- Transmission type:Imported Linear railway/Rack and pinion
- Control Method:Offline movement Control
- Cooling Mode::Water Cooling
- Power supply:380V/415V +/-10% 50-60Hz
- Position Accurancy:±0.03
- Protection level:IP54
1. High-rigidity heavy chassis, reducing the vibration generated during high-speed cutting greatly.
2. Gantry double-drive structure, German rack & pinion transmission system, improves the production efficiency.
3. High-performance cast aluminum guide rail, after finite element analysis, realizes highly accelerated speed circular arc cutting .
4. Open worktable, simple operation and small space occupation.
Technicial Parameters of the sheet metal fiber laser cutting machine price
|
Processing format
|
2000mm×4000mm
|
|
Laser type
|
Fiber laser generator
|
|
Laser power(optional)
|
500W~1000W
|
|
Transmission system
|
Gantry double-drive system
|
|
Lubrication system
|
Full-automatic
|
|
Maximum speed
|
60m/min
|
|
Maximum accelerated speed
|
0.8 G
|
|
Position accuracy
|
±0.05mm/1000mm
|
|
Reposition accuracy
|
±0.03mm/1000mm
|
|
Compatible formats
|
PLT,DXF,AI,CAD etc
|
|
Working environment
|
Temp:0-40℃,humidity: ≤ 80%, No condensation
|
|
General power
|
Around 20KW
|
|
Power supply
|
Triphase 380V/50Hz/60Hz
|
|
Overall dimension
|
5500mm×3250mm×1650mm
|
|
Gross weight
|
6000Kg
|
Zhengzhou Baiwei CNC Machinery Shares Co.,Ltd. was established in 2004,main products are:Fiber laser cutting machine,CNC laser cutting machine,high-power laser cutting machine,YAG medium power laser cutting machine,electro-hydraulic servo CNC bening machine,CNC shearing machine,CNC plasma flame cutting machines,CNC turret punch press.We has strong R&D department,to meet customer specific requirements,we are willing to customized personalized products for you.
We are located in Zhengzhou high-tech industry district,university science and technology park,it covers 60,000 square meters,with modern plant 32,000 square meters.6,000 square meters of the industry's first thermostatic numerical control equipment assembly plant,to build a world-class sheet metal,cutting equipment.
