Quick Details
Description
- Condition:New
- Laser Type:Fiber Laser
- Applicable Material:Metal
- Cutting Thickness:0-30mm
- Cutting Area:2000*4000mm
- Cutting Speed:60-120m/min
- CNC or Not:Yes
- Cooling Mode:Water Cooling
- Control Software:Cypcut/Beckhoff/ PA8000
- Graphic Format Supported:AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
- Place of Origin:Henan, China (Mainland)
- Brand Name:BAIWEI
- Model Number:BW-G3015
- Certification:CE
- After-sales Service Provided:Engineers available to service machinery overseas
- Laser power:500w 1000w 2000w 3000w Fiber laser
- Warranty:2 Years
- Laser Head:Swiss Raytools/ America lasemech
- Driving System:Japan Servo motors
- Transmission type:Imported Linear railway/Rack and pinion
- Control Method:Offline movement Control
- Cooling Mode::Water Cooling
- Power supply:380V/415V +/-10% 50-60Hz
- Position Accurancy:±0.03
- Protection level:IP54
1. High-rigidity heavy chassis, reducing the vibration generated during high-speed cutting greatly.
2. Gantry double-drive structure, German rack & pinion transmission system, improves the production efficiency.
3. High-performance cast aluminum guide rail, after finite element analysis, realizes highly accelerated speed circular arc cutting .
4. Open worktable, simple operation and small space occupation.
Technicial Parameters of the sheet metal fiber laser cutting machine price
|
Processing format
|
2000mm×4000mm
|
|
Laser type
|
Fiber laser generator
|
|
Laser power(optional)
|
500W~1000W
|
|
Transmission system
|
Gantry double-drive system
|
|
Lubrication system
|
Full-automatic
|
|
Maximum speed
|
60m/min
|
|
Maximum accelerated speed
|
0.8 G
|
|
Position accuracy
|
±0.05mm/1000mm
|
|
Reposition accuracy
|
±0.03mm/1000mm
|
|
Compatible formats
|
PLT,DXF,AI,CAD etc
|
|
Working environment
|
Temp:0-40℃,humidity: ≤ 80%, No condensation
|
|
General power
|
Around 20KW
|
|
Power supply
|
Triphase 380V/50Hz/60Hz
|
|
Overall dimension
|
5500mm×3250mm×1650mm
|
|
Gross weight
|
6000Kg
|
Advantages
1. Application of gantry structure and integrated cast cross-girder to achieve higher rigidity, stability, shock resistance.
2. High-performance laser source and stable operating system which make the best cutting effect.
3. The machine owns perfect cooling system, lubrication system and dust removal system, to ensure that it can operate stably, efficiently and durably.
Zhengzhou Baiwei CNC Machinery Shares Co.,Ltd. was established in 2004,main products are:Fiber laser cutting machine,CNC laser cutting machine,high-power laser cutting machine,YAG medium power laser cutting machine,electro-hydraulic servo CNC bening machine,CNC shearing machine,CNC plasma flame cutting machines,CNC turret punch press.We has strong R&D department,to meet customer specific requirements,we are willing to customized personalized products for you.
We are located in Zhengzhou high-tech industry district,university science and technology park,it covers 60,000 square meters,with modern plant 32,000 square meters.6,000 square meters of the industry's first thermostatic numerical control equipment assembly plant,to build a world-class sheet metal,cutting equipment.
