Quick Details
Description
- Condition: New
- CNC or Not: Normal
- Power Source: Pneumatic
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: JULY
- Model Number: JLCX101D-800KG
- Voltage: 220V
- Power(W): 5.5kw
- Weight: 110kg
- Dimension(L*W*H): 500*400*1050 mm
- Certification: CE
- Warranty: one year
- After-sales Service Provided: Overseas service center available
- Pressure capacity: 0.5 T
- Cylinder Adjustable Stroke: 50 mm
- Stroke: 100 mm
- Working Height: 250 mm
- The Size of The Working Table: 350*250 mm
- Driving Pressure: 0.4-0.7MPA
- Start Button: Two Hand Safety Push Buttons
- Safety Sensor: Customer Optional
- Structure Type: Single Column
- Custom-tailor: Available
|
Model
|
JLCX101D-100
|
JLCX101D-125
|
JLCX101D-160
|
JLCX101D-200
|
|
Force
|
500kg
|
800kg
|
1200kg
|
2000KG
|
|
Working height
|
250
|
250
|
250
|
250
|
|
Cylinder size
|
φ100*100
|
φ125*100
|
φ160*100
|
φ160*100
|
|
Adjustable stroke
|
50
|
50
|
50
|
50
|
|
Power
|
AC220V,50Hz
|
AC220V,50Hz
|
AC220V,50Hz
|
AC220V,50Hz
|
|
Driving pressure
|
0.4-0.7MPa
|
0.4-0.7MPa
|
0.4-0.7MPa
|
0.4-0.7MPa
|
|
Weight
|
90
|
110
|
140
|
160
|
|
Driving pressure
|
Theoretical output
|
|
0.4Mpa
|
294kgf
|
458kgf
|
753kgf
|
1206kgf
|
|
0.5Mpa
|
368kgf
|
573kgf
|
942kgf
|
1507kgf
|
|
0.6Mpa
|
442kgf
|
688kgf
|
1130kgf
|
1809kgf
|
|
0.7Mpa
|
515kgf
|
802kgf
|
1319kgf
|
2110kgf
|
Characteristics
1.Pneumatic presses powered by compressed air,noise,pollution-free environment.
2.Mini type light up less space,are widely used in small parts of the pressing,molding,assembly,riveting,printing,punching,cutting,bending,stamping and other light duty precision requirements.
3.Pneumatic presses results enough simple,smooth performance,and less maintenance,according to the size of the product or the mold height adjustment;
4.Beer gas system of the safe operation of their hands,others can be optional foot control;
5.Turn the cylinder with only the guide rod,a more accurate history of work;
6.Pneumatic presses can increase the heating temperature control mold and electrical boxes(for hot,mark);
7.The output power of 100-2200KG for choice;
8.Optional work table,dimensions:650*550*700mm
9.Special requirements of an acceptable order.
