Quick Details
Description
- Condition: New
- CNC or Not: Normal
- Power Source: Pneumatic
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: JULY
- Model Number: JLYA-100KG
- Voltage: 220V
- Power(W): AC220V 50HZ
- Weight: 47kg
- Dimension(L*W*H): 200*352.5*880mm
- Certification: CE
- Warranty: 1 year
- After-sales Service Provided: Overseas service center available
- Pressure capacity: 0.1T
- Cylinder: Diameter 63*100MM
- Cylinder Adjustable Stroke: 50mm
- Driving Pressure: 0.4-0.7MPA
- Output Pressure: 124KGF-218KGF
- Start Button: Two Hand Safety Push Buttons/Foot Switch
- Safety Sensor: Customer Optional
- Structure Type: Single Column
- Working Height: 85-365mm
- Custom-tailor: Available
|
Model
|
JLYA-63
|
JLYA-80
|
JLYA-100
|
JLYA-125
|
|
Working height
|
85-365
|
80-360
|
80-380
|
70-370
|
|
Cylinder specification
|
Ø63*100mm
|
Ø80*100mm
|
Ø100*100mm
|
Ø125*100mm
|
|
Power
|
AC220V,50Hz
|
AC220V,50Hz
|
AC220V,50Hz
|
AC220V,50Hz
|
|
Driving pressure
|
0.4-0.7MPa
|
0.4-0.7MPa
|
0.4-0.7MPa
|
0.4-0.7MPa
|
|
Weight
|
47kg
|
49kg
|
67kg
|
70kg
|
|
Driven pressure
|
Theoretical output
|
|
0.4MPa
|
124Kgf
|
201Kgf
|
314Kgf
|
491Kgf
|
|
0.5MPa
|
160Kgf
|
251Kgf
|
393Kgf
|
613Kgf
|
|
0.6MPa
|
187Kgf
|
302Kgf
|
471Kgf
|
736Kgf
|
|
0.7MPa
|
218Kgf
|
352Kgf
|
550Kgf
|
859Kgf
|
Characteristics
1.It is pneumatically driven,export thrust,simple to operate.
2.No hydraulic system noise, can save electricity consumption and thus reduce production costs.
3.Adjustable cylinder stroke and customized for special request.
4.Easy to adjust the output, the required pressure can be reached by simply regulating the air pressure.
5.Safety and humanity design that ensure operation comfort and long lifespan .
6.Allows adding heating modules and temperature controller, as well as forcing transducer additionally.
7.Available working platform: 500*560*610mm (L*W*H).
