Quick Details
Description
- Type:Labeling Machine
- Condition:New
- Application:Commodity
- Packaging Type:Bottles
- Packaging Material:Plastic
- Automatic Grade:Automatic
- Driven Type:Electric
- Voltage:AC220V 50/60HZ
- Power:0.3 KW
- Place of Origin:Guangdong, China (Mainland)
- Brand Name:Fuhe
- Model Number:KWTB
- Dimension(L*W*H):1800x700x1800mm(LxWxH)
- Weight:200Kg
- After-sales Service Provided:Engineers available to service machinery overseas
CHARACTERISTICS
1. The machine adopts technology mature touching PLC control system so as to make the machine working stable and high speed.
2. The operation system with touching screen control, easy operation, practical, high efficiency.
3. The use range is large, it is used in many specifications oral liquid and ampoule bottle etc spindly cylindrical material labeling
Enclosed rolling pressure loss label attached to weld more firmly
4. Dedicated to cannot stand or stand instability slender label. For example: liquid bottles, small injection, ball pen, batteries, etc.
TECHNICAL SPECIFICATIONS
|
Model
|
KWTB
|
|
Voltage Specification
|
AC220V 50/60HZ
|
|
Consume Power
|
300W
|
|
Labeling Speed
|
0~300 bottles /min
|
|
Labeling Precision
|
±1mm
|
|
Range
|
Outer diameter 7~20 mm,height 30~80 mm
|
|
Use Range
|
Height 15~80 mm,length 10~65 mm
|
|
Overall Dimension
|
1800×700×1800mm(L×W×H)
|
Guangzhou Fuhe Packaging Machinery Co., Ltd. is an enterprise which designs, manufactures and sells packaging machines and provides related services.
The vertical automatic packaging machines we provided are widely used in packing the slice & grain, liquid and powder of foodstuff, medicines and chemical products.
With the innovative and responsible attitude, Fuhe is providing high quality products, competitive prices and satisfactory services for clients based on excellent equipment, advanced designs, manufacturing process and a strict quality management system.
We will continue to develop new products to meet and satisfy your requirements. It is desired and certain that you will benefit from our high quality products and satisfactory services. We would like to establish stable relationships with all our customers and make progress together. Your patronage and esteemed suggestions are welcome.
