Quick Details
Description
- Type:
-
Other, general
- Condition:
-
New
- Application:
-
Food
- Packaging Type:
-
box
- Packaging Material:
-
Plastic
- Automatic Grade:
-
Automatic
- Driven Type:
-
Electric
- Voltage:
-
220V
- Power:2.8 Kw
- Place of Origin:Guangdong, China (Mainland)
- Brand Name:Fuhe
- Model Number:DXDZ250/350
- Weight:300kg
- Dimension(L*W*H):3770*670*1450mm
- After-sales Service Provided:Engineers available to service machinery overseas
- Usage:outer
- Material:stainless steel
- Key word:cake packing machine
- Type packing:Packing Machine
Suitable range
Suitable for the soft ,long and bulk type thing, like: towel, facial tissue, noodle, egg roll, sausage, sleeve-fish, ice-lolly, soft sweet, cookies, fresh fruit.
Main features of function and structure
1. Double frequency changer control, the bag length instant designing and instant cutting .No need to waste the films when you adjust the bag length. Set a matter at one go. Time and film saving.
2. Human-machine interface, simple and easy to setup the parameters
3. Automatic diagnose the stoppage, the stoppage is clear at a glance.
4. High sensitive photoelectric color code tracing, sealing position input digitalizing, which can make the sealing position more accurate
5. Independent PID control, more ideal for various materials
6. Enable to fixed-position and machine halt, no adhesion to the knife, no film wasting.
7. Succinct driveline, steady performance, and convenient maintaining
8. All the controls are realized by software, convenient to adjust the functions, and easy to upgrade, never falling down.
Alternative device
1. colored tape printer
2. ruled middle sealing round
3. cobweb end-sealing mould
4. super-big touching screen
TECHNICAL SPECIFICATIONS
|
model
|
ASZB-250X ASZB-350X
|
|
film with
|
Max250mm Max350mm
|
|
bag length
|
65~190mm or 120~280mm
|
|
bag with
|
30~110mm 50~160mm
|
|
product height
|
Max.40mm
|
|
Film roller diameter
|
Max.320mm
|
|
packing speed
|
40~230bags/min
|
|
specification
|
220V,50/60HZ,2.4KVA 220V,50/60HZ,2.8KVA
|
|
machine dimension
|
(L)3920×(W)670×(H)1320 (L)4020×(W)720×(H)1320
|
|
machine quality
|
800Kg 900Kg
|
Guangzhou Fuhe Packaging Machinery Co., Ltd. is an enterprise which designs, manufactures and sells packaging machines and provides related services.
The vertical automatic packaging machines we provided are widely used in packing the slice & grain, liquid and powder of foodstuff, medicines and chemical products.
With the innovative and responsible attitude, Fuhe is providing high quality products, competitive prices and satisfactory services for clients based on excellent equipment, advanced designs, manufacturing process and a strict quality management system.
We will continue to develop new products to meet and satisfy your requirements. It is desired and certain that you will benefit from our high quality products and satisfactory services. We would like to establish stable relationships with all our customers and make progress together. Your patronage and esteemed suggestions are welcome.
