Quick Details
Description
- Type:Other, Packing Machine
- Condition:New
- Application:Chemical
- Packaging Type:Bag
- Packaging Material:other
- Automatic Grade:Automatic
- Driven Type:Electric
- Voltage:220V
- Power:3kw
- Place of Origin:Guangdong, China (Mainland)
- Brand Name:FUHE
- Model Number:DXD-2000FB
- Weight:800kg
- Dimension(L*W*H):3770*670*1450mm
- After-sales Service Provided:Engineers available to service machinery overseas
- Usage::outer
- Machine material::304 stainless steel
- Key word::packing machine
Advantages:
1. High automatic level, compact structure, attractive appearance.
2. Convenient and Simple operation, low labor intensity.
3. Safe and reliable and adjustable continuous production capacity.
4. made up of 304 stainless steel.
Main filling material:
milk powder , washing powder , chemical fertilizer.
Technical parameter:
|
Packing material
|
Powder
|
|
Model
|
DXD-2000FB
|
|
Packing range
|
300--2000ml
|
|
Filling type
|
Stepper motor + Auger
|
|
Film width
|
MAX 440 MM
|
|
Bag size
|
L80-310mm W120-200mm
|
|
Packing rate
|
10-50 Bag/min
|
|
Control type
|
PLC+ touch interface
|
|
Air consumption
|
0.6Mpa 300L/min
|
|
Power
|
3Kw
|
|
Power supply
|
AC 380V 50Hz / AC 220V 50Hz
|
|
Weight
|
G.W.650kg
|
|
Overall dimension
|
L1330mm W1140mm H2460mm
|
|
Sealing Method
|
Back sealing
|
|
Packing material
|
Paper/PE, PET/PE, OPP/CPP Complex film
|
Guangzhou Fuhe Packaging Machinery Co., Ltd. is an enterprise which designs, manufactures and sells packaging machines and provides related services.
The vertical automatic packaging machines we provided are widely used in packing the slice & grain, liquid and powder of foodstuff, medicines and chemical products.
With the innovative and responsible attitude, Fuhe is providing high quality products, competitive prices and satisfactory services for clients based on excellent equipment, advanced designs, manufacturing process and a strict quality management system.
We will continue to develop new products to meet and satisfy your requirements. It is desired and certain that you will benefit from our high quality products and satisfactory services. We would like to establish stable relationships with all our customers and make progress together. Your patronage and esteemed suggestions are welcome.
