ccd wheel alignment machine
Main Feature
-Windows XP, Win 7, Win 8, Linux operating system with customer management and data memory.
-6-8 meters long wheel base measuring, suitalbe for passenger car, pickup, truck and bus.
-WiFi wireless communication make the signal transmission more accurate, stabale and reliabale.
-8 tracks CCD measuring with electronic level.
-3 points run-out compensation measurement.
-Over 10000 vehicle data are saved in PC and new data update can be easily downloaded at Doyo's website.
-Wheel base, track width and axle offset measurement.
-Steering wheel angle measurement and difference value measurement between left wheel and right wheel.
-Self diagnosis for system breakdown and error message.
-Caster lock and lifting lock .
-Self-service multi-language display system.
-3000mA Lithium rechargeable battery and intellegent battery charger make system continuously work more than 30 hours.
-Automatic power off about 5 min after working.
Technical Data
|
Item
|
Range
|
Accuracy
|
|
Toe
|
±10°
|
±2′
|
|
Total Toe
|
±20°
|
±4′
|
|
Camber
|
±12°
|
±2′
|
|
Caster
|
±20°
|
±4′
|
|
SAI
|
±20°
|
±4′
|
|
Thrust angle
|
±8°
|
±2′
|
|
Turning angle
|
±24°
|
±4′
|
|
Range of clamp
|
10″﹣20″or 12″﹣25″
|
|
Clamp range: 10"-22"
Power supply: 220V/110, 50/60Hz
Monitor: 20" LED
Input power: 600W
Console Dimension: 660X650X1150
![]()
![]()
![]()
![]()
![]()
![]()
![]()
