Quick Details
Description
- Type: Wrapping Machine, General
- Condition: New
- Application: Beverage
- Packaging Type: wooden crate
- Packaging Material: Plastic
- Automatic Grade: Semi-Automatic
- Driven Type: Electric
- Power: 1.5kw
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: MQS
- Model Number: MP206-M
- Carriage: Powered Pre-stretch
- Pre-stretch Ratio: 250%
- Usage: Outer
- Turntable Diameter: 1500mm / 1650mm / 1800mm
- Max Pallet Size: 1200mm L * 1000mm W
- Max Wrapping Height: 2100mm
- Control: PLC
- Turntable Speed: 0-14RPM
- Approval: ISO9001, CE
Proudct Introduction:
Stretch wrapping machines are used to wrap stretch film around a loaded pallet. Film provides extra support during transportation and storage to protect them from dust, moisture or damage. It’s been widely used in industries such as glassware, tools, electric & electronic, paper, pottery, food & beverage, etc.
Product Features:
*Powered pre-stretch film carriage, ratio 250%.
*Dual chain structure column, carriage speed vairable.
*Automatic wrapping according to pre-set parameters. Friendly user interface for setting wrap cycles, top/bottom cycles & film tension. Manual wrap mode as an option.
*Auto height detection, turntable home position, forklift sockets for easy moving.
*Dual limit switches on top & bottom to provide better safety protections.
Product Specifications:
Turntable Diameter: 1500mm, optional 1650mm,1800mm
Wrapping Height: 2100mm, optional 2400mm,2600mm
Loading Weight: 2000kg
Packing Speed: 20-40 pallets/hour
Turntable Speed: 0-15rpm,speed variable, turntable soft start & soft stop
Turntable Height: 82mm
Carriage Speed: 3m/min
Control: PLC
Working Mode: auto/manual
Power: 1PH 220VAC, 50/60Hz, 20A, 1.35kw
Dimensions: 2565 x 1500 x 2535mm
Machine Weight: 700kg
