Quick Details
Description
- Type: Wrapping Machine, Laminating Machine
- Condition: New
- Application: Beverage, Food, Other
- Packaging Type: Case
- Packaging Material: Wood
- Automatic Grade: Automatic
- Driven Type: Electric
- Voltage: 380V/50HZ
- Power: 17kw
- Place of Origin: Beijing, China (Mainland)
- Brand Name: Beijing Runda
- Model Number: SF5545
- Dimension(L*W*H): 6680*1580*1430
- Weight: 2500kg
- Certification: CE ISO9001
- After-sales Service Provided: Engineers available to service machinery overseas
- Max sealing size: L(any size) *W60-450*H5-150MM
- machine size: L6680*W1580*H1430MM
- machine speed: 0-60m/min
- power: 17kw
- FCL: Panasonic
- Electrical control system: Panasonic
- frequency transfer: Panasonic
- Breaker: Schneider
- relay: Schneider
1.It is suitable for high speed shrink wrap packing of any packages.such as books,magazine,food and so on.
2.It’s formed by four units of automatic book loading unit,automatic cutting and sealing unit,heat circulating shrink stove and automatic book unloading units.
3.This composition has the advantage of high efficiency and low cost,should be an ideal production machine for and packing industry.
1.Automatic book loading,avoiding mistake led by manual operation.Four units could be moved separately according to production layout.
2.Automatic film feeding at any step.Adjusted by electric eyes (switching between horizontal and vertical group)and timing device,to guarantee
3.Stable packing,cutting and sealing process,Continuous hot cutting by Teflon coated constant temperature blade at any step,transferring speed is 1m/sec.high quality,high speed,no adhesion,no breakage,zero consumption.
4.Integrated heat controlling system,heat circulating shrink stove,free adjusted wind direction,double layers.
Technical parameters
|
Packaging size range (mm)
|
(L)unlimited×(W)60-450×(H)5-150
|
|
Max Mechanical speed
|
0-60m/min
|
|
Outline sizes(mm)
|
6680×1580×1430
|
|
Total power
|
17kw
|
