• heavy duty professional manufacturer multiple depth drive in bays for logistics storage

heavy duty professional manufacturer multiple depth drive in bays for logistics storage

Min.Order Quantity: 100 Piece/Pieces Supply Ability: 100000 Piece/Pieces per Week Port: nanjing port Payment Terms: L/C,T/T,Western Union

Product Details

Quick Details


Quick Details

  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: multiple depth drive in bays
  • Model Number: multiple depth drive in bays
  • Type: Pallet Rack
  • Scale: Heavy Duty
  • Capacity: Requirements
  • Material: Steel
  • Usage: Warehouse
  • Feature: Anti-rust
  • Color: Blue and Orange
  • Loading Capacity: as request
  • Application: Steel Pallets Widely Used
  • Finish: Chrome Galvanized
  • Design: Easy Accessibility

Packaging & Delivery

Packaging Details standard export packing
Delivery Time Shipped in 20 days after payment
heavy duty professional manufacturer multiple depth drive in bays for logistics storage

Drive in pallet racking is used where high density storage is required. It is frequently used in facilities with a low number of product lines. It works on the FILO first in last out rule. Drive in racking is designed for high storage density without special pathway. The forklift would drive in the aisles when loading or picking pallets. Drive-in racking has good storage density, suitable for material warehouse or cycle warehouse with high efficiency or timely operation.


One. Main Features

Drive In Racks:

Drive In Racks allow vehicles to enter the storage area for pallet placement in a back-to-front arrangement, and require the operator to back-out of the rack after pallet placement. Drive In Racks are ideally suited for "FIRST-IN / LAST-OUT" inventory management. Drive In systems can also be designed as "double entry systems" in a back to back arrangement. Double entry systems allow for greater density and allow for entry on both sides of the system.

Drive Thru Racks:

Drive Thru Racks have two access aisle for loading and retrieval. Lift Trucks can pass through the rack bay, placing loads on supporting rails from one side, and exit in the same direction. Trucks can also enter the rack bay for the opposite side to remove loads. Drive-Thru Racks are well suited for  "FIRST-IN / FIRST-OUT" inventory movement . Both Drive-In and Drive-Thru systems offer the advantages of high-density storage and lower costs.


Drive In / Drive Thru Rack Application

Suit for large storage and few types; Forklifts driving in directly for laying and retrievaling cargos with First-In First-Out or First-In Last-Out; With pallet loading capacity of 500~1500kg/pallet. Various colors for choice. Special making according to clients' requirements.
Remark: Specific orders for High efficient store Drive In Rack are welcome.


Two.  When should you specify  Drive In Rack

 1. Drive-In Rack is used to store many pallets of a similar SKU or product. Lift trucks drive into the rack to extract the first pallet they come to. This is "Last-In, First-Out" storage.

2.We've installed Drive-In and Drive-Through Racks in a number of cold storage applications, due to the need to store as many pallets as possible in as little expensive freezer space as possible.

3.When you have seasonal items that move quickly out of your inventory.

4.When you have a large amount of similar items that can be stored in a single pallet position and accessed last-in, first-out.

5.If you don't store a wide variety of loads in the rack.


Three.  High efficient store Drive In Rack  Load Rail Design

Load Rails are constructed of durable structural angle steel, providing increased strength and abuse resistance. Standard features include:

1.Structural angle rails "guide" pallets, ease of use and durability

2.Flared rail entry ends allow easy bay access

3. Space-saver low profile arms increase clearance and decrease possible product damage

4.Welded rail stops prevent loads from being pushed off, improving safety

5.75mm vertical adjustability

6.Welded aisle-load arms to eliminate hazardous load projections into aisles

7.Grade 5 hardware


Four.   Please inform us of the following information for quick quotation:

1. Drawing (if available)
2. Size of your warehouse
3. Size of racking (H*W*L)
4. How many levels of the racking?
5. Loading capacity of each pallet?
6. (RAL) Color you want.
