• fruit juice production line/ juice filling equipment / manufacturer/production line

fruit juice production line/ juice filling equipment / manufacturer/production line

After-sales Service Provided: Engineers available to service machinery overseas; matrial: stainless; company: factory trade; capacity: 2000-4000;

Product Details

Quick Details

Description

  • Type: Filling Machine
  • Condition: New
  • Application: Beverage
  • Packaging Type: Bottles
  • Packaging Material: Paper, Wood
  • Automatic Grade: Automatic
  • Driven Type: Electric
  • Voltage: 280V/330V
  • Power: 2.2KW
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Greenfall Angle
  • Model Number: CGF16-12-6
  • Dimension(L*W*H): 2350*1610*2250
  • Weight: 3000KG
  • Certification: CE ISO UL
  • After-sales Service Provided: Engineers available to service machinery overseas
  • matrial: stainless
  • company: factory trade
  • capacity: 2000-4000



The Description of Water Filling Machine

1.Automatic 3 in 1 Small Water Filling Machine  adopt Rinsing/Filling/Capping 3-in-1 technology, PLC control, Touch Screen, it is mainly made of SUS304 or 316

2.It is used for filling kinds of non-carbonated water, such as still water,mineral water,flavored water,spring water .

3.Its usual prodcution capacity is in 2000-40000bph, 0.3-2L PET bottle is available.

4.Pivotal electrical part use Mitsubishi, OMRON, SIEMENS

5.Filling accuracy is more or less than 1%



Main Technical Data  OF Water Filling Machine

Model

CGF16126

CGF18186

CGF24248

CGF323210

CGF404012

washing, filling and capping  heads

16-12-6

18-18-6

24-24-8

32-32-10

40-40-12

Production capacity (b/h)

2000-4000

5000-7000

8000-12000

12000-15000

16000-20000

suitable bottle specification

φ=50-110=170 330-2250ml

Washing pressure(kg/cm 2 )

2-3

Motor power(kw)

2.2kw

3kw

5.5kw

7.5kw

11kw

Overall dimensions(mm)

2600×1920×2550

3100×23002800

3800×2800×2900

4600×2800×2900

5450×3300×2900

Weight (kg)

3000

4000

6000

8000

9500

fruit juice production line/ juice filling equipment / manufacturer/production line

Company Profile

Jiangmen Greenfall Water Treatment Technology Co.,Ltd is a specialized manufacturer of water bottling machines and Reverse Osmosis drinking water purification machines. With the support of the engineers with extensive bottled water engineering experience, since the state-owned period, Jiangmen Greenfall Water Treatment Technology Co.,Ltd has been covering 70% of the domestic market. Also with encouraging sales records from the past 16 years, World class companies, such as WAL-MART, CULLIGEN WATER BOTTLING, BYD, CARREFOUR, WANSA and AL JAZEERA have become our essential customers.

Jiangmen Greenfall Water Treatment Technology Co.,Ltd has become the one-stop contract manufacturing company providing the services below:

1. Industrial Reverse Osmosis drinking water purification plants ranging from 300LPH to 20000LPH based on different water conditions.

2. full auto complete line 3-10L, 3 and 5 gallon water filling machine is at the capacity range from 60bph to 1200 bph.

3. Different capacity full auto complete line mineral/ pure water, carbonated beverage filling machines, for 250ml-2L bottles. Also 100-1000ml, 3-10L pouch packing machines


4. Basic to high standard bottle blow molding machines and plastic packaging machinery to be fully synchronized with the bottled water filling lines.

5. Upper grade high quality bottled water dispensers and water coolers with ISO, CE standard which help customer build quality-oriented brand image.

As one of the leading manufacturers in drinking water treatment and bottled water engineering (covering water dispensers) in China, we are pursuing good reputation in the global market also. Our products are selling well in Canada, French, Jordan and Indonesia, and we have more customers from Mexico, Ecuador, Australia, Singapore, Thailand and Brunei. We have a good beginning in most of African countries.

Providing "Quality Products, Excellent Service, Competitive Prices and Prompt Delivery", we are now looking forward to even greater cooperation with overseas customers based on mutual benefits. If you are interested in our products, please feel free to contact us for more information.
