• YC series single-phase capacitor-start electric motors

YC series single-phase capacitor-start electric motors

YC series single-phase capacitor-start electric motors single-phase HEAVF-DUTY capacitor-start motors AC induction motor asynchronous motor Please contact us:wangxun124@163.com

Product Details

Quick Details


Product name:YC series single-phase capacitor-start electric motors
Categories:YC series
These single-phase HEAVF-DUTY capacitor-start motors are made to IEC standards.
 These are superior motors delivering excellent torque enabling the toughest jobs to be handled with dependable ease. They perform well in high voltage fluctuating regions and are commonly used in the pumping, compressor, agriculture,farming, building service and manufacturing industry. When rated output is 3HP or below, motors with capacitors start, and 4HP or above with capacitor start and run.

.IP44 enclosure
.Class B insulation, Class F available on request
.Low operating temperature
.High quality magnet wire
.Vacuum varnish impregnation for superior tropic proof insulation
.Continuous S1 operation
.Industrial type service factors
.Heavy duty ball bearings
.High strength cast iron frame
.Balanced rotors
Customer benefits:
·Water dust and vermin resistant
·Quiet operation
·Corrosion resistant
·Reliable in country, city or factoryenvironments
·Very low vibration
·Very low power consumption
·Superior life
·Suitable for hot evironments
·Low start current and EMC interference


Company Profile

TAIZHOU YANGCHUN ELECTRIC MOTOR CO.,LTD. LOCATED AT WENLING CITY, ZHEJIANG PROVINCE. About 20km from HuangYan airport, the transportation is very convenient.
      Our company established in June, 1996, own design, produce, sales, service together. we are professional produce motor, water pump. Our factory has many experience of producing water pumps, motors with automatic assembly line in the process of parts,spray lacquer and package.
      Specialized in water pump such as pure water pump, diving pump, deep well pump, centrifugal pump, vortex pump surfing pump and electric motor such as YC, YL,JY single phase motor and Y Y2 MS three phase motor. Completed and various specifications,advanced design and well selected material, unique technology with superior performance, safe, reliable and high endurance.
      Our products received praise from both domestic and foreign customers, meanwhile the products have been sold to over 20 domestic provinces and more than 10 countries and regions all over the world, such as Europe, the Middle East,Southeast Asia, South America and Africa.
      Our company has passed ISO9001:2000 quality certification, and the products already got CCC and CE certification. We firmly believes that science and technology are the first productivity,relying on quality to survive in the squeal competition,relying on scientific and technological innovation to develop yourself and explore new markets. According to the market demand,we will try our best to creat first class enterprise.
