Quick Details
Description
Place of Origin: Guangdong, China (Mainland)
Material: Stainless Steel Wire, Stainless Steel Wire, 302,304,316,316L,8020
Type: Weave Wire Mesh
Application: Woven Wire Mesh, Mine Sieving Mesh,and Basket,etc
Weave Style: Plain Weave, Plain Weave
Wire Diameter: 0.018mm
Technique: Woven
Model Number: 1-1000 mesh
Brand Name: Boda
Product name: Welded wire mesh
Hole: 0.0455mm
Mesh size: 1-500
Width: 0.3M-5M
Length: 15M-100M
Diameter: 0.018mm-2mm
Feature: Anti-acid, Resistant to rust
Delivery Time: In 20-30 days
MOQ: 1 roll
Woven style: plain,twill,dutch
Mesh :1-635mesh
Diameter: 0.0008"-0.08"
Roll Width: Max 240"
Roll Length: Max 2000'
MOQ: 1 roll
Packaging & Delivery
| Packaging Details |
30m/roll woodenbox |
|---|
| Delivery Time |
in 20-30 days |
|---|
Characteristics :Made by stretching and drawing through moulds, the product is characterized by acid-alkali resistance, high tensile strength, intercrystalline corrosion resistance, smooth surface and bright color.
Performance : Heat resistance, acid resistance, alkaline resistance, strong tension and good abrasion resistance.
| Stainless steel wire mesh |
| mesh/inch |
wire diameter
mm |
aperture
mm |
|
mesh/inch |
wire diameter
mm |
aperture
mm |
| 2mesh |
1.80 |
10.90 |
60mesh |
0.15 |
0.273 |
| 3mesh |
1.60 |
6.866 |
70mesh |
0.14 |
0.223 |
| 4mesh |
1.20 |
5.15 |
80mesh |
0.12 |
0.198 |
| 5mesh |
0.91 |
4.17 |
90mesh |
0.11 |
0.172 |
| 6mesh |
0.80 |
3.433 |
100mesh |
0.10 |
0.154 |
| 8mesh |
0.60 |
2.575 |
120mesh |
0.08 |
0.132 |
| 10mesh |
0.55 |
1.990 |
140mesh |
0.07 |
0.111 |
| 12mesh |
0.50 |
1.616 |
150mesh |
0.065 |
0.104 |
| 14mesh |
0.45 |
1.362 |
160mesh |
0.065 |
0.094 |
| 16mesh |
0.40 |
1.188 |
180mesh |
0.053 |
0.088 |
| 18mesh |
0.35 |
1.060 |
200mesh |
0.053 |
0.074 |
| 20mesh |
0.30 |
0.970 |
250mesh |
0.04 |
0.061 |
| 26mesh |
0.28 |
0.696 |
300mesh |
0.035 |
0.049 |
| 30mesh |
0.25 |
0.596 |
325mesh |
0.03 |
0.048 |
| 40mesh |
0.21 |
0.425 |
350mesh |
0.03 |
0.042 |
| 50mesh |
0.19 |
0.318 |
400mesh |
0.025 |
0.0385 |
| Width of Stainless Steel Wire Mesh: 0.6m-1.5m |
Specification of stainless steel wire mesh
| Type |
Mesh/Inch |
Wire diameter(inch) |
OPen Area |
Weight (LB) /100 Square Foot |
| Plain,Twill Weave Wire Mesh |
1 × 1-635 × 635 |
0.0008"-0.08" |
25 to 84.6 |
2.53 to 41.1 |
| Type |
Mesh/Inch |
Wire diameter(inch) |
Absolute Filtration Finess µm |
Nominal Filtration Finess µm |
| Plain Dutch Weave Wire Mesh |
8 × 85-80 × 400 |
0.014'' × 0.0126''- 0.0049'' × 0.0028'' |
318-340 to 43-48 |
250-255 to 35-40 |
| Twill Duntch Weave Wire Mesh |
20 × 250 - 500 × 3200 |
0.0098'' × 0.0079'' - 0.0015'' × 0.0010'' |
110-120 to 8-9 |
98-105 to 2-3 |
2.Product application
In acid, alkali environment conditions sieving and filtering
Petroleum industry as mud mesh
Chemical fiber industry as screen mesh
Plating industry as acid cleaning mesh
3.Weave style
Type : Plain ,Twill, Plain Dutch , Twill Dutch, Reverse Dutch Weave and Five-Heddle Weave.
![]()
we are a professional manufacturer of wire mesh manufactures,main products are:304,316 stainless steel crimped wire mesh ,304,316 stainless steel welded wire mesh,304,316 stainless steel crimped wire mesh,304,316 stainless steel mesh,nylon net,hook flower net,steel nets,galvanized steel plate etc.
