• Solar vacuum tube coating machine(OEM for your requirement)

Solar vacuum tube coating machine(OEM for your requirement)

 Automatic solar thermal collectors coating machine control system This equipment is full automatic control,adopt single target or multiple target configuration. Solar thermal collectors can plating system, also can be in metal pipe, plate solar absorption membrane plating system.

Product Details

Quick Details


  Control system adopts double single chip microcomputer control structure, modular design, with high reliability, easy operation, automatic monitoring, etc; And have the function of fault alarm processing; Process can be arbitrarily set by the user, control points more interlock, reduce downtime generated because of man-made wrong operation. Process, the machine automatically complete the process. The machine according to the requirements of users plating system of different specifications of the glass tube (only change different wheel and check, can be coated with different diameter glass tube), achieve multi-usage. The equipment for reasons of energy saving, according to user needs, optional electromagnetic heater to heat diffusion pump oil, can energy saving 30%; Power supply can choose dc inverter type power supply, energy-saving 35%.
The main technical indicators: 1, extreme pressure:
 1.33 x or less 10-3 pa
 2, restore time: by the air pump to 6 x 10-3 pa < 10 min
model Vacuum chamber specification Vacuum unit Plating pipe specifications Pipe number Target number DC power is The power number
JYZC-720 Φ720×(2030-2800) JKQ-500  JKQT-600 Φ37×(1500-2200) 32 1 63Kw 63Kw
Φ47×(1500-2200) 28
Φ58×(1500-2200) 24
JYZC-850 Φ850×(2030-2800) JKQT-600 Φ37×(1500-2200) 40 3 63Kw 63Kw
Φ47×(1500-2200) 32
Φ58×(1500-2200) 28

Company Profile

 Ningbo Junying Vacuum Science and Technology Co., Ltd.that is Founded in 2003, is a leading vacuum coating engineering integrated provider in China. Is a collection development, design, production, foreign trade and service of high-tech enterprises. we create maximum value for customers through our close dedication to customer-centric innovation.
The products we manufacture are as follows: evaporative coating machine, multi-arc ion coating machine, multiarc ion magnetron sputtering machine, medium frequency magnetron sputtering coating machines ,electron beam coating machine, continuous evaporation (magnetron sputtering) coating production lines, more than features such as multi-layer film coating machine series vacuum coating equipment.
There are a series of special machine for special products: These products are widely used in solar energy、semiconductor、Low-E glass、photoelectricity、flat panel display、tools and cutters、watches、hardware、3C、plastic、ceramic etc.Our company have perfect R&D and manufacture system、customer service system.There are many domestic and foreign experts working with us.Our products and craft have been deployed all over the world. Selling products in Russia, India, Malaysia, Turkey, Brazil, Mexico and Egypt Syria, Iran and Israel American etc
The company's aim is first-class quality, first-class service ,Dedication to the community. Customer demand is really our goal.
Because the focus, so professional!
