ZheJiang YonJou Pump&Valve Technology Co.,Ltd

Year Established:2013

Business Type:

Management Certifiation:

Contact Supplier Visit Minisite

More from this Supplier

  • Skid Mounted Diesel Engine Driven Dewatering Pumps

Skid Mounted Diesel Engine Driven Dewatering Pumps



Applications

? Water & waste water

? Construction & civil engineering

? Oil & Gas

? Mining

? Marine

? Municipal

? Industrial


Send Inquiry  Add to My Favorites

Product Details

Quick Details

Description

Product Description

Product Description:

The YP Skid Mounted Diesel Engine Driven Dewatering Pumps is a range of general purpose,self-priming, free standing site pump. The pumps can be used in a range of environmental conditions, including tropical temperatures.

Each pump is capable of passing solids up to the specified maximum diameter for the size of machine(see Table 1, page 2), provided the solids are in suspension; a typical example being ditch water containing soil and rock particles. Slurry may also be pumped, if concentration of solid matter is not too high. The pumps can also handle abrasive materials at the expense of higher wear rate. (For advice on the suitability of your pump for specific applications contact YONJOU).

YP pumps are normally powered by a diesel engine with electric start.They are supplied on a four wheeled site trailer, two wheeled site trailer or two wheeled high speed road trailer chassis.



Applications

? Water & waste water

? Construction & civil engineering

? Oil & Gas

? Mining

? Marine

? Municipal

? Industrial




Certifications
Detailed Images

Pump

Pump type: End suction centrifugal pump

Impeller type: Semi-open or helical

Seal: Double mechanical seal with water cooling systel

Pump body material:Cast Iron

Impeller material:Cast Iron

Shaft material:2Cr13

Vacuum System

Vacuum pump type: water ring
Displacement: 14l/s, 30l/s
Parameter: 25CFM, 60CFM

Vacuum level:9.5m

Lubricating oil:30 SAE viscosity below 30℃
10W30 SAE above 30℃

Normal Speed:2900RPM

Diesel Engine (Drive main pump and vacuum pump)

Engine optional: Deutz, Perkins, Cummins,Weichai
Engine cooling type: Water cooling or air cooling
Original: China



Trailer

Trailer optional: two wheels, four wheels
Original: China

Factory View
Our Service

YP100

Max flow:150m3/h

Max discharge head:32m

Max solid handling:20mm

Max lift:9.5m

YP125

Max flow:200m3/h
Max discharge head:34m
Max solid handling:26mm
Max lift:9.5m

YP150

Max flow:340m3/h
Max discharge head:42m
Max solid handling:32mm
Max lift:9.5m

YP200

Max flow:540m3/h
Max discharge head:53m
Max solid handling:40mm
Max lift:9.5m

YP250

Max flow:1000m3/h
Max discharge head:60m
Max solid handling:50mm
Max lift:9.5m

YP300

Max flow:1800m3/h
Max discharge head:55m
Max solid handling:65mm
Max lift:9.5m

Related Products

Diesel engine split case pump

91.8% Response Rate

Diesel engine end suction pump

91.8% Response Rate

Diesel engine self priming pump

91.8% Response Rate

Abroad Exhibitions

China YONJOU Pumps

Contact: James Deng /Forest Yang

China YONJOU Pumps

Contact: Marcia Chen

China YONJOU Pumps



Company Profile

ZheJiang YonJou Technology Co., Ltd is specialized in industrial pumps and valves since1989. Now YONJOU has three bases for the production. The pumps are exported to 150 countries and regions.

YONJOU pumps and valves cover petrol chemical industry, agriculture, metallurgical industry, electric power industry, shipbuilding industry etc. The company' S success is also confirmed by the ISO9001: 2008, CE, SGS, TUV, PICC and other certificates.

Now YONJOU is ICBC"AAA"grade credit enterprise with good reputation, ZheJiang good faith enterprise, Wenzhou well-known trademark, YongJia famous brand, ZheJiang Pump&Valve premium brand, Wenzhou innovative technology enterprise.

YONJOU follows the purpose of "Developing by technology, Living by quality, Benefitting by customer, Seek to supply customers with qualified products and satisfied service".

Please contact us immediately for more details.
