Quick Details
Parameter
Rated Voltage : 200-800V
Capacitance: : 5-30kvar
Description
Main Parameter
Rated voltage: 415, 480, 525,820 and 900V AC
Rated capacitance: 1 to 60kV AR
Capacitance tolerance: -5 to +10%
Tangent of the loss angle: ≤0.15%
Installation direction: top or side
Feature
Small volume, light weight: it is only 1/4 and 1/5 of the weight and volume of the outdated products respectively
Low loss: with the actual loss less than 0.1, little radiation, low temperature rise and good energy conservation effect
Excellent self-healing performance: when a part of the isolation is fed through due to the over voltage, it is capable of self-healing so as to continue the operation, reliability is improved greatly
Safety: equipped with self-discharging resistant and safety devices inside, inner discharging resistant can make the attached electric discharged, when there is wrong with the capacitor, fuse equipment can cut out the electric power, so that no more trouble with the capacitor, safety and reliable
Without oil leakage: product adopts advanced half-solid materials drips Milton-g point higher than 70°C, avoid leakage during operation and protect environment, the capacitor will not no use since the leakage
