• SANY P816s 8m3/h output diesel trailer mortar pump

SANY P816s 8m3/h output diesel trailer mortar pump

Sany P816S mortar pump with the high-pressure and large displacement system outputs 8 cubic meter per hour with an outlet pressure of 8 MPa. The 8 cubic meter mortar pump is capable of pumping to a height of up to 100m.

Product Details

Quick Details

Description

Condition: New Application: Construction Place of Origin: Hunan, China (Mainland) Brand Name: SANY Model Number: P816s Dimension(L*W*H): 5587 mmx1804 mmx2364 mm Weight: 3918 kg Certification: ISO9001:2008 Warranty: 12 Months After-sales Service Provided: Engineers available to service machinery overseas Type: Mortar Pump Output: 8 m3/h Pressure: 8 Mpa Max. strokes per minute: 8 times/min Delivery cylinder diameter: 120 mm Stroke length: 1400 mm Hydraulic system: Open Hydraulic system oil pressure: 16 Mpa Oil tank capacity: 260 L Hopper capacity: 0.4 m3
Packaging & Delivery

Packaging Details: Mortar Pump Comply with export packaging requirements
Delivery Detail: Shipped in 30 days after payment


SANY P816S mortar pump

Benefits& features
Sany P816S mortar pump with the high-pressure and large displacement system outputs 8 cubic meter per hour with an outlet pressure of 8 MPa. The 8 cubic meter mortar pump is capable of pumping to a height of up to 100m.

High Efficiency Pumping System

Hydraulic double-cylinder piston pumping system delivers smoother flow and spraying.

Automatic lubrication system extends the service life of the pistons.

Improved material path reduces pumping resistance and pipe blockages.

Superior pump control valve design, equipped with high-pressure relief valves, ensure safe and easy cleaning.

Advanced Hydraulic System

Innovative hydraulic system design matches any job application in the field.

The high-pressure, large displacement system outputs 8 m³/h with an outlet pressure of 8 MPa. Capable of pumping to a height of up to 100m.

Electronically controlled reversing function provides quick, smooth direction change and optimizes pumping continuity.

Constructed with globally recognized, quality components.

Precise Control System

The SANY developed SYMC control system offers real time control and monitoring on a high-definition display.

Automatic pre-start checks provide worry free operation.

Ergonomic design provides precise control and reduces operator fatigue

Company Profile

The Sany Group was founded in 1989 as a small welding materials factory. Today, it is the largest construction machinery corporation in China and the fifth largest globally. Two of its member companies are listed on separate stock exchanges; Sany Heavy Industry Co., Ltd. on the Shanghai Stock Exchange and SANYHE International Holdings Co., Ltd. on the Hong Kong Exchange. And Sany Heavy Industry Co., Ltd. was the first-ever Chinese business to successfully achieve the government-owned enterprise transfer to the private sector under the non-tradable stock reform program. It is also listed among the world's top 500 companies in the construction machinery industry.

Today, Sany is the leading brand in China for concrete pumping machinery, excavators, crawler cranes, rotary drilling rigs and coal mining machinery. And Sany concrete pumping machinery is No. 1 worldwide.

Each year, Sany allocates between 5% and 7% of its total sales revenue to R&D projects, with the goal of providing even more world-class products for customers everywhere.

At this time, Sany has state-of-the-art technology development centers and post-doctoral research centers. As of June 30, 2014, the Sany Group had applied for over 7,500 patents. With over 5,000 patents already authorized, the Sany Group ranks No. 1 in the industry.

While constantly working to improve its product quality, the Sany Group is also committed to providing comprehensive and world-class cu
