Quick Details
Parameter
Name : SAIHENG Durable Commercial Conveyor Gas Pizza Oven
Key words : gas oven
Use : food baking and drying
Description
SAIHENG Durable Commercial Conveyor Gas Pizza Oven
Introduction
|
Type
|
|
Introduction
|
|
Gas Type
|
![GAS OVEN.jpg]()
|
1)The machine is heated with gas(LPG or natural gas).Rapid heating up and energy saving.
2)The oven is grouped into heat control zones. The top and bottom heat are independently adjustable and preset. The measured temperature and preset temperature will be displayed in digital form.
3)To allow independent movement of the chamber to relieve stresses when expanding or contracting.
4)High-quality thermal insulating material is used to get good insulation and efficient fuel usage.
5)Steel work, ducts and chambers paint with high temperature (400C) silvery paint. Outer covers paint with hard finish gloss paint.
6)Oven band level:1100mm
7)Fully automatic PID temperature control and automatic constant temperature.
8)Highest temperature:360C
9)Great control flexibility and prefect safety precautions.
10)Available in Lengths from 30 to over 150 meters.
11)Programmable logic controllers (PLC) and touch-screen control system are used.
12)It can meet the technological requirements for production of different food.
|
|
Electric Type
|
![biscuit machine 3.jpg]()
|
1)This tunnel oven is composed of oven tunnel, mesh belt , belt driving system, chimney, electric heating pipes and control cabinet.
2)The heater adopts infrared heating to make the biscuit baking equally.
3)Frequency inverts control cabinet makes more accurate temperature controlling and wider temperate regulate range
4)The oven is separate to several individual heating zones as per different formulas. Each Zone has can be regulated individually.
|
Baking Samples
![.jpg]()
Warm tips:1.The length and width can be customized according to customer's rquirment,the date only for reference,are subjected to change without notice.
Technical Parameters
GasType
|
Model
|
SH-280-1
|
SH-400-1
|
SH-600-1
|
SH-800-1
|
SH-1000-1
|
SH-1200
|
|
Each Part(m)
|
4
|
4
|
4
|
4
|
4
|
4
|
|
Dimension(m)
|
16*1.2*1.8
|
28*1.45*1.8
|
40*1.6*1.8
|
40*1.8*1.7
|
60*1.85*1.8
|
60*1.96*1.6
|
|
Baking Temp.(℃)
|
190-240
|
190-240
|
190-240
|
190-240
|
190-240
|
190-240
|
|
Power(kw)
|
6
|
6
|
11
|
18
|
17
|
560
|
|
Weight (kg)
|
2000
|
7000
|
15000
|
30000
|
40000
|
45000
|
|
Capacity(ton/8hour)
|
0.8-1
|
2
|
4
|
6
|
8
|
10
|
Electric
|
Model
|
SH-280
|
SH-400
|
SH-600
|
SH-800
|
SH-1000
|
SH-1200
|
|
Each Part(m)
|
4
|
4
|
4
|
4
|
4
|
4
|
|
Dimension(m)
|
16*0.64*1.1
|
28*0.92*1.35
|
40*1.1*1.45
|
40*1.3*1.45
|
60*1.76*1.6
|
60*1.96*1.6
|
|
Baking Temp.(℃)
|
190-240
|
190-240
|
190-240
|
190-240
|
190-240
|
190-240
|
|
Electric Power Needed (kw)
|
55
|
190
|
240
|
320
|
480
|
560
|
|
Weight (kg)
|
1800
|
8400
|
12000
|
16000
|
37500
|
45000
|
|
Capacity(tons/8h)
|
1
|
2
|
3-4
|
6
|
8
|
10
|
Our services:
Product:
1.We can customized the products according to the customers requirement .
2.We can provide the most favorable and competitive products' prices.
3.We have excellent sales team and after-sell team. good after-sell service.
4.our delivery is on time.
Warranty:
The products’ warranty period is within two years from the date of the B/L on board to calculate, free offer accessories(except burner, motor and glass cloth),unless by the force majeure factors or artificial damage, the specific decision through the photos. If the machine has any problem, our sales will be responsible for following up until your problem to be solved.
Packaging ang Delivery:
water proof film package on all parts
electric control box wooden case package
all big parts have frame for easy loading and unloading
Company & Factory Information:
![.jpg]()
Shenghua Group Hebei Saiheng Food Processing Equipment Co.,Ltd is an industrial company with rich experience, specializing in the manufacturing of various types of food machine. The company’s main products: biscuit production line,wafer production line,baking oven.
We have our own factory and professional technicians,we have years of experience in production,the quality of the products are ensured.Our products have passed some professional certifications,such as CE,BV,ISO,SGS.We insist that you buy peace of mind,with a more assured.
We welcome you to visit and search for business opportunities!
Shenghua Group Hebei Saiheng Food Processing Equipment Co.,Ltd is an industrial company with rich experience, specializing in the manufacturing of various types of food machine. The company’s main products: biscuit production line,wafer production line,baking equipment. "Good quality is the key to survive, Good credit standing is the key to develop" is the enterprise purpose of SaiHeng. With the management philosophy of "quality, service, innovation", under the efforts of SaiHeng people, the company achieves a rapid improvement in sales value year after year. The company’s products are exported to Britain, Japan, Ireland, France, Africa and other parts of the world.
Nowadays, food safety is becoming a more and more serious problem, China's food machinery equipment upgrading has become a big trend. On the existing technology, Our company constantly introducing foreign advanced technology and continue innovation to make the company’s produced equipment gradually in the leading level in the food machinery industry at home and abroad. The whole production line operation, improves the degree of automation, reduces the repair rate, and the production has improved a lot.
