RAEX dc electric motors 24 volt MD360

Specifications 1. Quiet,DC drapery motor; 2. Automatic limit setting, 2. touch control technology 3.built in receiver

Product Details

Quick Details

Description

Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
RAEX
Model Number:
MD360
Usage:
Home Appliance, Household Appliance
Certification:
CCC, CE
Type:
Micro Motor
Torque:
1.2Nm
Construction:
Other
Commutation:
Brush
Protect Feature:
Waterproof, Waterproof
Speed(RPM):
112rpm
Continuous Current(A):
1.2A
Voltage(V):
24V
Function:
Driving
Structure:
Automatic limit setting
Phase:
Three Phase
Speed:
Constant Speed
Shape:
Linear
Power:
24VDC
Packaging & Delivery
Packaging Details
18pcs/ctn Size:44.5*36.5*40.5cm
Delivery Time
1~7working days after payment

Raex china DC drapery motor MD360

Features:

1.Quiet ,DC motor

2.touch control technology ,gently pulling the curtain to open or close the curtain

3.touch control function can be switched and off

4.intergrated  control ensures operation of the curtain manually in case of power failure

5.full automatic setting of the limits ,cushion stop function to protect impact mid-way stop function is available

6.mid-way stop function is available

7.built in radio receiver, switch and\or network control

8.easy to install and operate

9.compact aluminum track available for straight and curve cur



10.textile teeth belt is durable and quiet, can stand heavy curtains and frequent operation



Parameters:

Product
Name
Rated
Voltage
Rated
Frequency
Rated
Current
Rated
Torque
Rated
Speed
Speed
Insulation
Class
Protection
Index

Running Time

MD360-0.8D
24VDC
--
1.2A
0.8Nm
112rpm
0.16m/S
I.cl.E
IP41
S3 30%
MD360-1.2D
24VDC
--
1.5A
1.2Nm
112rpm
0.16m/S
I.cl.E
IP41
S3 30%
MD360-0.8A
100-240VAC
50/60Hz
0.8A
0.8Nm
112rpm
0.16m/S
I.cl.E
IP41
S3 30%
MD360-1.2A
100-240VAC
50/60Hz
0.8A
1.2Nm
112rpm
0.16m/S
I.cl.E
IP41
S3 30%



MD360-0.8D/MD360-1.2D
Measurement: 265mmX50.6mmX60mm
Net Weight: 1.19kg
MD360-0.8A/MD360-1.2A
Measurement: 305mmX50.6mmX60mm
Net Weight: 1.4kg
