Quick Details
Description
- Condition: New
- Type: Slitting Rewinder
- Computerized: Yes
- Place of Origin: Zhejiang, China (Mainland)
- Brand Name: LR
- Model Number: F1600
- Voltage: 220V/380V
- Power(W): 1.5kw
- Dimension(L*W*H): 2200*1500*1100mm
- Weight: 600kg
- Certification: CE Certificate
- Warranty: 1 Year
- After-sales Service Provided: Engineers available to service machinery overseas
- Maximum material width: 1300mm
- Minimum width of finished product: 20mm
- Maximum diameter of raw material:600mm
- Diameter of finished product coil: 450
- Speed of parting cut: 0-100m/min
PERFORMANCE AND CHARACTERISTICS:
The machine adopts high speed frequency conversion,energy conservation, photoelectric tracking, automatic rectification of discharging, discharge magnetic particle brake, material receiving magnetic particle clutch.
It compared with the similar machine, higher precision, less waste, faster and achieved maximum benefit for you.
|
Maximum material width
|
1300mm
|
|
Minimum width of finished product
|
20mm
|
|
Maximum diameter of raw material
|
600mm
|
|
Diameter of finished product coil
|
Φ450
|
|
Speed of parting cut
|
0-100m/min
|
|
Power of motor
|
1.5kw
|
|
Voltage of power supply
|
220v/380v
|
|
Overall dimensions (L*W*H)
|
2200*1500*1100mm
|
|
Weight
|
600kg
|
WenZhou LianRun Machinery Co.,Ltd. Is a professional manufacturer of non-woven fabric making machine, Non-woven bag making machine, Non-woven printing machine, Non-woven soft handle sealing machine, Film Blowing Machine, Printing Machine, Bag Making Machine, Zipper Machine, Bubble Film Machine, Stretch Film Machine, Plastic Recycling Machine and relevant equipment.
We formed a team with responsible and professional machine designers, senior engineers, senior salesman, after sale service worker since we established.
We have our own workshops, exhibition center, sales team, guided by "people-oriented, honest management,customer-first,Sincere service" business philosophy,
