Quick Details
Description
- Model NO.: TMAX
- Structure: Moulded Case Circuit Breaker
- Function: Overcurrent Protection
- Pole Number: 3
- Trademark: Kasan,Aolkw,Neutral,OEM
- Origin: Zhejiang China (Mainland)
- Speed: High-Speed Circuit Breaker
- Type: Circuit Breaker
- Certification: CE
- Standard .: IEC60947-2
- Specification: ce
KTMAX MCCB is suitable for circuit AC 50Hz/60Hz, rated voltage up to AC 660V rated operating current up to 250A. It features normal structure, reliable performance, high breaking capacity, used for power distribution and protecting the circuit and electrical equipment against overload and short circuit. It complies with standatd of IEC60947-2.
|
Type
|
KTMAX-160
|
KTMAX-250
|
|
Poles number
|
3
|
3
|
|
Rated current In(A)
|
16~160
|
100~250
|
|
Rated operating voltage Ue(V) (50/60Hz)
|
690
|
690
|
|
Rated insulation voltage Ui(V)
|
800
|
800
|
|
Rated impulse withstand voltage Uimp(kV)
|
8
|
8
|
|
Utilization category
|
A
|
A
|
|
Rated limited short-circuit breakking capacity Icu(kA)
|
220/230V
|
25
|
50
|
|
380/415V
|
16
|
36
|
|
400V
|
10
|
25
|
|
500V
|
8
|
20
|
|
690V
|
3
|
5
|
|
500-3poles in series
|
16
|
36
|
|
Rated short-circuit service breakking capacity Ics
|
100
|
75
|
