Quick Details
Description
Please contact us:chensong@mec.com.cn
1 .Adopt a higher precision Servo system, with PLC & AC inverter intelligent and step-less controlling .which can realize simple operation and more correctly cutting.
2 .High-sensitive photo sensor, automatically adjust, track,find cutting point, accumulatively count packs,Automatic measure bag length.
3 .Digital and independent PID temperature controlling,suitable for various packing materials.New type double fin sealing design makes the packaging high efficiency and beauty.
4 .Adjustable bag former and pitches,enable the change of packing products conveniently.
5 .The area connect to products are full stainless steel.With timing belt transmission,Compact structure, lower noise and less shake.
6 .Variety of optional device is available,Like:Touch screen/Date coder/Labels applicator/Euro slot or hole punch/Gusset forming /Nitrogen or gas inflation/Spraying alcohol/Automatic film splicer/Auto feeding/Desiccant feeder /Auto falling/Products conveyor/No products no packing / Check weigher / Metal detector etc.
Using range
Mainly used for various kinds of solid objects with regular shape(Square/Rectangle/Circular/Ellipse/Flake etc.),such as moon-cake, muffin cake,bread, fruit pie,biscuits,swiss roll,sweets, chocolate, pharmaceuticals tools,medicine,daily necessities, hardware, or any other products loaded in box or tray.
Technical paramete
| Model |
JY-420F |
| Packing speed (bag/minute) |
30-200bag/min |
| Packing size (mm) |
L80-350 |
| Length x Width x Height |
W10-60/60-120 H5-40/40-70 |
| Maximum width of film (mm) |
<420mm |
| Thickness of film (mm) |
≥0.02mm |
| Power |
220V,50/60HZ,3.0KW |
| Overall size (mm) |
4400*940*1640mm |
| Weight |
650kg |
| Package |
2.8CBM.2CASES |
| Packing material |
OPP/PP、OPP/CPP、PT/PE、PE、KOP/CPP OPP/PP、OPP/CPP、PT/PE、PE、KOP/CPP、PT/PE/、AL/PE etc. Any heat-sealable composite materials foil/film |
