Purpose:
The machine is suitable for dividing and cutting the large coil material, such as printing packaging material, film, paper, cloth and all kind of paper plastic complex material including spraying paper, coated paper, chemical leather etc.
Performance And Features:
Adopt imported pneumatic round cutter, which has the features of high cutting precision and easy operation. The cutter can be regulated optionally.
Adopt A and B shaft to wrap up separately. Mantle and disassemble easily.
Receiving and discharging shafts adopt the inflatable shaft. The tension can be controlled automatically. Wrap up the finished products tidily and compactly.
Discharging support has the function of hydraulic automatic lifting.
Have automatic waste-discharging device.
Machine has the functions of the frequency speed adjustment, microcomputer automatic control, photoelectric rectifying device, automatic counting, giving an alarm and stopping and tension display.
|
Model
|
DB2-1100
|
DB2-1300
|
DB2-1600
|
DB2-1800
|
|
Max.Unwrapping Diameter
|
1400mm
|
|
Max.Cutting Breadth
|
1100mm
|
1300mm
|
1600mm
|
1800mm
|
|
Max.Wrapping Diameter
|
800mm
|
|
Min.Wrapping Breadth
|
50mm
|
|
Speed of Dividing&Cutting
|
120m/min
|
|
Total Power
|
12kw
|
13kw
|
15kw
|
17kw
|
|
Suitable Power Supply
|
380V/50Hz Three photo electricity
|
|
Air Pressure Source
|
Max 0.5m3/min
|
|
Weight
|
3000kg
|
3500kg
|
4000kg
|
4500kg
|
|
Overall Dimensions(mm)
|
3500×2000×1500
|
3500×2300×1500
|
3500×2800×1500
|
4000×3000×1600
|
