  • Heavy duty lathe machine

Heavy duty lathe machine

It can turning excircle, inner bore,end face, grooving, drilling, bore a hole and jacking. it is big hole . Please

Product Details

Quick Details


 Max swing over bed mm(in) 1000(40) 1250(50)
  Max swing over gap-bed mm(in) 1250(50) 1500(60)
 Max swing over cross slide mm(in) 645(26) 895(36)
 Distance between centers mm(in) 1500-16000(60-640)
  Max work piece weight bewteen centers kg 6000,8000
   Spindle nose ISO A2-15
   Spindle bore  mm(in) 130(5.2)  100(4)
  Taper of spindle bore   Metric No.140
  Spindle speed grades prograde 21grades(Manual operating)
   Spindle speed grades reversal 12 grades(Manual operating)
Range of spindle speed r/min 3.15-315   2.5-250
 Range of spindle speed r/min 3.15-315   2.5-250
   main motor power kw AC22
 Rapid moving motor kw 1.5
Size of tool handle mm(in) 45×45(1.8×1.8)
  Turret swing angle   ±90°
 Compound rest travel    300(12)
  Cross slide travel mm(in) 520(21) 695(27)
  Compound rest feeds range  mm/min 935
  Cross slide feeds range mm/min 1870
  Longitudinal feeds range mm/min 3740
 Threads metric pithces mm 45,1-120
  Threads inch pithces T.P.I. 42,30-1/4
 Threads module pithces mm 46,0.5-60
  Threads diametral pithces D.P. 48,60-0.5
 Longitudinal feeds pithces m/rev 56,0.1-12
  Cross feeds pithces m/rev 56,0.05-6
   Turret feeds pithces m/rev 56,0.025-3
   Tailstock quill diameter mm(in) 160(6.4)
   Quill taper   Metric No.80,Morse No.6
   Quill travel mm(in) 300(12)
  Machine N.W  (3 mm model) kg 10800 11500

Company Profile

 We can manufacture various machine tools, such as universal lathes, CNC lathes, vertical drilling machines and machining center.

Our company was established in 1985 with fixed assets exceeding RMB300 million. Our company has independent import and export rights authorized by the State Foreign Economic Trade Committee. Our products are exported to over sixty countries and regions around the five continents. Our products had been given the golden praise of "Mexico-Chinese Practical Economic and Product Trade Exhibition" and the "19th International Golden Star for Excellence in Corporate Appearance and Quality Award".

We are devoted to the innovation of technology and management, and have formed strict, practical and continuously innovative business culture. With the approval of technology committee, our company established a R&D center, which organizes the planning, development and innovation of multiple products, and has developed seven series, over twenty types and over sixty grades of products. The advantages of our CNC lathes are advanced structures, novel types, high quality, high performance and low prices.

Our company was awarded the honors of "Star Company in China" and "Attaching Importance to the Contract, Keeping the Prestige" and our products were awarded titles of "High Quality Products in Guangdong Province" and "Famous Brand Products in Guangzhou City".
