Quick Details
Description
- Place of Origin: Zhejiang, China (Mainland)
- Brand Name: SENTAI
- Model Number: TSM9
- Type: Mini
- Poles Number: 1P 2P 3P 4P
- Certificate: CE,CB
- Standard: IEC60898-1
- Rated voltage: 230/400V
- Rated frequency: 50/60 Hz
- Curve: B, C, D Curve
- Rated current In(A): 6A-63A
- Breaking Capacity: 10KA
- Handle Color: green
- Mechanical Life: 20000 Times
- Material: PA66 case
APPLICATION
TSM9-63 series circuit breaker is the new product developed by our factory. The breaking capacity can
pass 10kA, it is used in the circuit of distribution systems for building and similar use, for untrained
person use, no need maintained. This series products applied the latest scientific research achievement
and the newly contrivance thinking, has many patent technical. This product conforms to IEC 60898 and
GB10963-1999 standards.
New:
A) The power input from underside to upside, conform to the path of power line or the wire of
distribution box, make the wire shorter, so it can reduce the cost of wire.
B) The super ARC chamber and special constructure of contact block, can extinguish the electrical ARC
very quickly, suitable to make the product can pass 10kA breaking capacity easily.
C) The handle is in the upside, touch feeling is comfortable and safety during on/off actions.
D) There is one special tage on the upside of the front of the product. It can by used in marking or
numbering by oil pencil.
FEATURE
All the terminal connecter is multi-function if tighten the screw, upside can connect with copper
connector, underside can connect with round wire separately. And also can combine with the copper
connecter (flat) and round wire at the same time for both sides. It has the visible contact block breaking
indicate equipment, can be used in wire isolating Full-scale:
A) The operation characteristic can be made as B.C and D style. It can meet different demands.
B) Combined with earth leakage protect equipment, can be used as earth leakage circuit breaker.
C) Combined with isolated tripping instrument or voltage shortage tripping instrument, it can realize far
distance control and voltage shortage protection.
D) Combined with contact block or warning instrument and other accessories, will be used in the power
supply systems of morden intelligent architecture.
Zhejiang Sentai Electrical Apparatus Factory, established in 1992, is a leading manufacturer & exporter of low voltage electrical apparatus in China, our main products are Circuit Breaker, AC Contactor, Thermal Relay and others, which are exported to all over the world including ASEAN, East Europe, South America, Middle East, Africa. Quality is life for us, then we have got many international certificates: ISO9001, ISO14001, Semko, CB,CE, etc.
