Quick Details
Description
- Place of Origin: Fujian, China (Mainland)
- Brand Name: DGSL
- Model Number: DOF
- Usage: High Voltage
- Breaking Capacity: High
- Safety Standards: ISO9001, ISO14001, OHSAS18001
- Product Name: Ceramic Fuse Pole Mounted Type 15kV Dropout Fuse Cutout
- Rated Voltage: 10-15kV
- Rated current: 100A
- Material: Porcelain Insulator
- Product type: Overcurrent Protector
- Package: Carton Box
Fuse Cutout is an outdoor high voltage protection facility. DOF series fuse Cutout is applied to AC 50/60 Hz, rated voltage up to and including 12 (38) kV outdoor overhead distribution system. It is installed at high voltage side of transformer or branch line of distribution line to protect transformer or transmission line from short circuit and overload, to break and connect load current.
DOF series Fuse Cutout unit is composed of insulator supports and a fuse tube, static contacts is fixed on two sides of insulator support and moving contact is installed on two ends of fuse tube. Fuse tube is consisting of two parts, arcing extinguishing tube in inner side and epoxy glass tube outside. And the Tension Load Dropout Fuse Cutout increases the flexible auxiliary contact and the arcing-extinguishing shield to break and connect load current.
Features:
1. Widely applicable for 12,15,24,27,38KV power distribution as protector; Can protect transformer, capacitor, cable, branch cable; Can supply reliable overload protection and short circuit protection on right time;
2. Durable and corrosion resistant-Zinc impregnation on surface; UV radiation resistance
3. Excellent conductivity;
4. Solid copper casting ensures opening and closing reliable; Tripping is reliable;
5. Dropout Fuses installation is simple, Very simple to insert or unload fusion tube;
4. Fuse cutout can be installed arcing shield, single-phase exhausting or double-phase-exhausting as your prefer.
D.G. Solution Ltd. (DGSL) is a specialized company, handling electrical apparatus and service for Power Company and public system. Founded in beautiful Victoria of Canada, it has engaged in the process of research, design, produce of electrical switches and invest in the relative fields. Its product provides reliable guarantee for the power transmission and wide range of electrical contracting service are available for clients from the fields of power, electricity, business, industry and others.
D.G. Solutions (XIAMEN) Electric Co., Ltd. is a technical corporation, set up in China to provide electrical apparatus and service for power generating and transmitting under 40.5Kv grade. Locating in Coastal city of Xiamen, it focuses on electrical apparatus upgrade, technical introduction and promotion. It has the serialized equipment, advanced technologies, matured experience from parent company, equips with DGSL platform of quality control and management system and shares the latest product development, design and manufacturing method from Canada headquarters.
It has a capable research team, which can independently research and design according to the detailed requirement of domestic market. All the product meet the domestic and international standards. Following the excelsior tradition of parent company, it engaged in the design and produce of electrical switches and protection apparatus in order to enhance the safety and liability of power supply system. It has modernized standard factories, with introduced manufacturing lines, producing equipment and accurate testing equipment, which ensures the excellent quality of all products.
The company has gained certificates of ISO9001, ISO14001 and OHSAS18001 and continuously improves and regularly audits the internal operation mechanism to reach a more rational, efficient and organized level. Quality control is strictly followed throughout the whole design and manufacture process. The company sticks to the standards of ISO9001, ISO14001 and OHSAS18001. The satisfactory from our client is the only yard stick of the company performance and it will try its best to meet their requirements of all product and service.
We warmly welcome customers from all over the world to visit us and cooperate in power and electric field!
