Quick Details
Description
Cotton seed oil pressing machine process flowchart:
Oilseeds → cleaning → softening → prepressing → drying → to extraction workshop
Cotton seed oil pressing machine instruction:
a. Cleaning device:remove the raw material peanut in various impurities, such as: iron,
stones, clump, such as the plant leaf, clean up till impurity content does not exceed 0.2%.
b.Crushing machine: peanut is crushed into 6-8 pieces. In order to meet the requirements
of crushing, the peanut is suitable for crushing with the moisture of 7% to 12%.
c. Softening process:the purpose of softening is to adjust the moisture and temperature
of oil, and make it soft.
d.Flaking process: rolling raw material into flakes, and the purpose is to increae surface
area, destroy the peanut cell tissue, shorten the way of oil out from cake.
e:Cooking process: use steam cooking, inject direct steam and cook the flakes to meet the requirement of oil press.
f.Pre-press: press the flakes to leave about 16%-18% in the cake. The cake will go to extraction process.
Extraction process:
1. Solvent pumps: continuously spray solvent to the rotary-type extractor
2. Roary extractor: Spray and soak the pre-pressed cake with solvent so that oil fats can be diss-olved in solvent(form miscella). After processing, you can get wet meal and miscella (mixed oil).
3. DTDC: usd to separate the solvent from the wet meal.
4. Miscella tank 1st: pump the miscella (oil with solvent) in to the miscella 1st , then add saline
water to it. The phospholipid in the miscella will react with the saline water, at last the reactant precipitate, reaching the goal of purifying.
5. Miscella tank 2nd: the purified miscella will be pumped into it.
6. Miscella stripping: it will remove the remaining solvent in miscella. And the solvent will be discharged to condenser for recycling.
7. Condensers: to cooling the solvent gas separated from the wet meal and miscella for recycling.
Zhengzhou Qi'e Grain&Oil Machinery Co.,Ltd is a large-sized joint-equity enterprise which specialize in producing edible oil mechanical equipment and it is also a group enterprise integrating scientific research, manufacturing, sales as one.
Our company have set up Mechanical Design and Research institution,oil press machine department ,large-sized complete oilequipmentdepartment,International trade department,production department.Our business involve in small-sized oil pressing series,Grain and oil engineering designing,equipment manufacturing and installing, project contracting,technical service ,new product development,the intensive and deep processing for oil by-products and so on.
The corporation lies in the High-Technology Industrial Development Zone of zhengzhou which is the capital city of Henan Province. It covers an area of 27000 square meters and contains 12 standardized production workshops,more than 100 sets all kinds of large and middle scale processing,plug welding and assembly equipment,,more than 200 online employee ,among them ,there are exceed 60 administrative staff and engineering technical personnel who hold intermediate and senior professional titles.
Our company have passed ISO9001:2000 international quality management system certification successfully.It has the qualification of manufacturing for one and two types of pressure vessel ,besides,it also has a number of national patents.Since founded in 1982,It has been awarded the "The quality-star enterprise of Henan province","Model enterprise with High quality, and keeping promises ","3.15quality and reputation double promise enterprise " and so on. Its Body shape"Qi'e" mechanical products have been awarded with"Chinese famous brand products","National Quality trusted consumer products" and many other honored titles.The pennants such as "High technical skills , reliable partners" from our customers are countless.
Our Company has grown into Chinese grain and oil machinery production and export base with scientific management method, strives for perfection the manufacturing process, innovative manufacturing idea rapidly , its production and the comprehensive economic indicators lies in the forefront of the same industry line, The products have been sold all over the country and exported to more than 30 countries and regions such as Russia, India, South Africa, Ukraine, Nepal, Indonesia and so on .
