Auto Fakra Antanna Adapter Cable
FAKRA Connectors and Cable Assemblies support applications that require a high-performing, reliable, and cost-effective RF connector. FAKRA connectors are standard SMB Connectors embedded within a special inter-locking plastic housing that uses multiple color-codes for easy identification and mating, and are designed to perform up to 4GHz at 50 Ω.
MAJOR CHARACTERISTICS
characteristic impedance: 50Ω
Temperature range: -45℃～+85℃
(The lower end of the wiring cable shall prevail)
Design structure and technical parameters:
RF coaxial connector: FAKRA SMB connector
Material:
Inner conductor: Brass,Gold-plated
Insulating medium: PTFE
Outer conductor: Brass, Nickel-plated
Electrical and mechanical properties: characteristic impedance: 50Ω
Frequency range: 0-4GHz
Medium Pressure: 1000V (60s)
Contact Resistance:
Inner conductor≤6mΩ Outer Contact≤1mΩ Insulation Resistance: 1000MΩ V.S.W.R≤1.3 (DC-4GHz)
Insertion loss:≤-15dB(0-4GHz)
Connectors mechanical life: ≥500 cycles
(frequency 12 cycles/MIN)
RF coaxial cable: RG174
Material: Inner conductor: Bare copper (7/φ0.16±0.003mm)
Dielectric: PE(φ1.52±0.05 mm)
Outer conductor:
Bare copper braided wire(80*φ0.10 mm)
Jacket: PVC(φ2.8±0.10 mm)
Physical electrical performance
Min Bent radius: 30mm
Max voltage: 1500 VMS
Temperature scope: -20℃～+80℃
Component overall specification requirements
Appearance:
Connector
Connector surface coating is uniform, no copper exposure, scratch (slight scratch is allowed but the metal under the coating shall not be exposed), oxidation, fracture, insulation deformation and other phenomena.
Cable
The cable is flat, smooth and without damage. No serious scratch is allowed.
Cable assemblies
The surface of the cable assembly shall be clean, free from dirt and bruises; Welding should be flat, no cracking, copper exposure and other phenomena; Reliable welding.
Shenzhen Sihanming technology Co., LTD（Shenzhen Sihan Communication Technology）was established in 2006, is a company that sets professional design, development, production, sales as one .Our main products are RF coaxial connectors,RF jumper ,MMCX connectors for earphone,test connector for Mobile phone, fakra automotive connectors, High frequency low loss test cable,high frequency test RF adapter and RF antennas. In the same time, we are the agent of Japanese I-pex .
2010: Company independently research and develop for automotive connector Fakra series products ,and formally put into production.and get several patent s of appearance and utility model .
2012: Shenzhen Sihanming Technology Co., Ltd passed ISO9001 .
2013: Shenzhen Sihanming Technology Co., Ltd passed IATF16949 .
2015:The LOGO "SH-Link" register successfully. In the same year our company was identified as" high-tech enterprise by "shenzhen science and technology innovation and technology commission “ and issue a certificate.
products and applications
1. These products are produced according to the international standard of SMA、SMB、SMC、BNC、TNC、N、MMCX、MCX、SSMA、SSMB and Fakra series etc. All of them are conform to the technical stands of IEC、DIN&MIL-C-39012.
2. 6G、20G、40G high frequency low loss test cable and test adapter .
3 .FAKRA automotive connectors、MMCX connectors for earphone、test connector for Mobile phone、IPEX series.
