Aluminum Double-head Cutting Machine for Aluminum Windows and doors
It is used for processing the pvc and aluminum profile , it has the feature of easy operation, reliable performance, advanced technology, easy to maintain. The cutter which is made of hard alloy saw blade has fast cutting speed, high efficient and accuracy. The two saw head can work together or seperatly, it can complete the cutting lenth as request for one time, the saw head can be turned to 45 and 90 degree.
Quick Details
Description
- Place of Origin: Shandong, China (Mainland)
- Brand Name: CNSUN
- Model Number: LJZ2-500*4200
- After-sales Service Provided: Engineers available to service machinery overseas
- Cutting Machine Input Power: 4.4Kw
- Air Pressure: 0.5-0.8Mpa
- Cutting Blade Specification:d30mm/D500mm
- Min aluminum cutting size: 500mm
- Max aluminum cutting size: 4200mm
- Usage: Aluminum profile for making windows and doors
- Leading guide: Imported linear guide
- Cutting angle: 45/90 degree
- Machine dimension: 5700*1750*1990mm
- Weight: 1800Kg
1.Description:
It is used for processing the pvc and aluminum profile , it has the feature of easy operation, reliable performance, advanced technology, easy to maintain. The cutter which is made of hard alloy saw blade has fast cutting speed, high efficient and accuracy. The two saw head can work together or seperatly, it can complete the cutting lenth as request for one time, the saw head can be turned to 45 and 90 degree.
2.Main Technical Parameters:
Power Supply:380V,50Hz
Input Power:3.6Kw
Air pressure:0.5-0.8Mpa
Blade Rotational Speed:3087r/min
Saw Blade Specification:D=450mm d=30mm
Cutting Length:Min580mm Max3700mm
Cutting Angles:45°90°
Jinan Sunny Machinery Co., Ltd. is a professional manufacturer of insulating glass machines, Vertical Glass Washing Machines, Glass Cutting Machines, PVC windows and doors machines, aluminum windows and doors machines.
Since established, relying on our strong research and development capability, advanced management mode as well as excellent workers team, our company gradually becomes the professional enterprise with professional production, professional management, and professional sale and after-sales services in a whole. Complying with ISO9001:2000 International Quality System Certification, we have consequently developed and produced six series including fifty types of products. Now our products have been sold all over the country and also have been exported to many foreign countries and regions, such as, Russia, Belarus, Ukraine, Korea, Mongolia, Argentina, Paraguay, Guatelama, Saudi Arabia, and Iran.
The new generation insulating glass system and aluminum doors and windows machines that developed by our company dedicated to the industrial development in building materials in Chinese chemistry, can produce every kind of products with such good properties as elegant appearance, varied colors, soundproof, water-tightness, heat insulation, waterproof and corrosion-resistant. And it can meet building requests on insulating glass and aluminum and PVC doors and windows and improve people's living environment.
On the basis of "Research and development as direction, quantity as the life, service as the mission", equipped with excellent after-sale service engineers with rich service experiences, our company can provide reliable technique and service for customers at times. Advanced production technology, perfect sales network and reliable after-sales service, bring about powerful strength and earn a good reputation of our company in the line of insulating glass machines and aluminum and PVC doors and windows equipments
Excellent product and perfect service, is the basis on which we cooperate with you; the most sincere pursuit and right choice is the bridge of our friendship. All employees of Sunny Company warmly welcome friends from all circles to come and discuss with us for mutual development.
