• 57mm 24V Brushless DC Brushless Motor

57mm 24V Brushless DC Brushless Motor

Samples in stock can be delivered within 7 days and customized samples within 30 days. Delivery date for bulk order depends on quantity.

Product Details

Quick Details

Description



Product Specification

Phase No 3 standard 57mm
Voltage 24V Body length 46.5mm
Rated Speed  3000rmp/min Weight 0.5kg
Peak Torque 0.38Nm Insulation Class B
output power 34W Ambient Temperature Range -20ºC~+ 50ºC
Phase Resistance 1.2Ω Insulation Resisitance 100ΩMin.500VDC
Phase Inductance 2.2mH Dielectric Strength 500V AC 1minute


Packages & Storage
-packages inside : Shockproof high-density foam box.
-package outside: hard carton offer effective protection.




Our main products
Hybrid stepper motor from 35-86
Linear stepper motor
Stepper motor driver
Brushless DC Motor
Servo motor



57mm 24V Brushless DC Brushless Motor

Company Profile

CZFL Stepper motor can be used in CNC machine, sewing machine and other industrial machine. The products above are conventional, it can be customized according to your requirements.

The factory specializing in the production of AC, stepper motor, AC servo motor, micro motor control and power control. Products are widely used in printers, shredders and other office automation equipment, but also widely used in CNC machine, packaging machinery, computer embroidery machine, automatic sewing machine in the computer industry, medical equipment, advertising and other equipment various automation equipment in the field. Products are sold to all over the country and export to Europe.

Application

CNC machine: Engraving machine, milling machine, coiling machine, sparking machine, wire-electrode cutting and so on.

Electronic equipment: Up-coiler, stripping machine, lithium battery production equipment, dispensing machine and so on.

Packaging equipment: Filling machine, fixed length cutting machine, tissue paper machine, paper diaper equipment and so on.

Textile equipment: Flat knitting machine, hosiery machine, embroidery machine, spinning machine, knitting machine and so on.

Laser machine: Screen printing machine, pad printing machine and so on.

Printing equipment: Carving machine, cutting machine, labeling machine and so on.

Others: Robot, unmanned aerial vehicle and so on.
