• 1000W Off Grid Solar Portable Power Sytem,Solar System (FD-OFF/MSS-1000W)

1000W Off Grid Solar Portable Power Sytem,Solar System (FD-OFF/MSS-1000W)

This is an off-grid energy system which uses batteries to store the solar energy, at the same time, the system can be connected with the grid for utilization of grid power.

Product Details

Quick Details


Solar Portable Power Sytem

Model: FD-OFF/MSS-1000W



Solar Portable Power Sytem

1. This is an off-grid energy system which uses batteries to store the solar energy, at the same time, the system can be connected with the grid for utilization of grid power.

2. The system uses battery power in priority, but when sunshine is not so good or loads consumption is too big which caused the battery power inadequacy, then the system can switch automatically to grid power supply.

3. Meanwhile, the system can charge the batteries with grid power until batteries are fully charged. Then the system will switch back to battery power supply



Solar Portable Power Sytemfeature:
1.Off-Grid Solar Enery System is composed of solar panels, controller, inverter, battery bank, solar panel mounting racks, and other accessories required for a complete system.
2.The solar panels generate electricity at daytime and charge the battery bank through the controller.
3.The battery bank gives a stable power output to the inverter which converts DC to AC to power loads, and provides power backup in rainy or cloudy days.
4.The controller gives an intelligent control of whole system process and provides various protections.


Solar Portable Power Sytem applications:

1. Living house and home building

2. Office building, factory and warehouse

3. Shopping mall, venue, stadium and so on

4. Power station, field operation and some huge engineer construction


Solar Portable Power Sytem details:


Item No FD-OFF/MSS-1000W
System Basic Information
Solar Panel Rated Output Power: 1000W
Suitable for Max Daily Power Consumption: 4KWH
Rated Output AC Capacity: 1KW
Solar Panel
Type Mono Crystalline Silicon PV Module
Max Power: 250W*4pcs
Vmp: 36V
Size: 1953×992×46mm
Weight: 22.5kg/pc
25 years power output guarantee
(Note: 2pcs panels in series as a string)
Inverter (UPS type)
Input voltage 1500W,DC48V
Output voltage AC220V  2-phase
Type Off grid type, automatic power tracking,
efficiency 97%
Warranty 5years
Solar Controller
Solar power support  1000W
Voltage 48V
Current 21A
Type MPPT charging controller, LCD display
Warranty 5years
Battery capacity 4pcs*12V/150AH per piece Gel Deep Recycle Battery
Solar panel rack
Ground or flat type mounting rack, including complete fittings; galvanized steel material
(Other types of racks can be customized as per client's requirement)
Cables 10mm2 size cable
Certifications CE RoHS
