straightener machine

straightener machine 1. roller quantity: up and down two-roller 2. roller shape: concave and convex rol Please contact:wangxun124@163.com

Product Details

Quick Details

Description

 straightener machine
Specification
JY40A
Raw

Material
Diameter Range(mm)
(excluding drawingmaterial)
Tensile Strength σb≤450(M pa)
Φ10≤d≤Φ40(L ≥2000)
Tensile Strength σb≤1000(M pa)
Φ10≤d≤Φ38(L ≥2000)
Surface Hardness
≤HB380(≤HRC42)
Straightness(mm/m)
Bright Steel≤3
Diameter Tolerance
Bright Steel≤IT10
Circular Degree
≤50% of diameter tolerance
Surface Roughness(Ra)
Bright Steel≤3.2mm~6.3mm
Finished

Products

Straightness(mm/m)
Bright Steel≤0.25
Diameter Tolerance
Bright Steel≤IT8
Surface Roughness(Ra)
Bright Steel≤0.8μm
Roller Quantity (pcs)
2
Roller Diameter(mm)
Φ200
Straightening Feeding Speed(m/min)
2~14
Main Machine Motor Power(KW)
30 X 2
Lifting Motor Power(KW)
1.1
Outline Dimensions (Length*Width*Height)
(for your reference)
Main Machine 5.5mX2.0mX2.4m
Full Set(including auxiliary machine)15.5mX3.6mX2.4m
Weight
(for your reference)
Main Machine 6.0 T
Full Set(including auxiliary machine) 11.0T
Total Capacity(for your reference) (KW)
62
Compressed Air Source(user prepare by themselves)
0.5~0.8MPa,3m3/min,two-stage oil-water sepe


Company Profile

Haige Machine Tools Co., Ltd. is a manufacturer of straightening machines and centerless turning machines with well-equipped testing equipment and strong technical force.

With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in Bars of various materials, wire processing and other industries.

Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs.

We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!
