single column cnc mini vertical turning lathe machine tool C516

1.hand scraping
2.60 years experience
3.own casting foundry
4.whole life after-sale service

Product Details

Quick Details Parameter

Place of Origin : Liaoning, China
Type : Vertical
CNC or Not : CNC
Max. Swing Diameter : 630mm
Voltage : 380V
Weight : 4t

Description

single column cnc mini vertical turning lathe machine tool C516


1.Usage range

 a. Turning the internal and external cylindrical surface and plane

 b. Turning internal and external conical surface

 c. Grooving

 d. Head face

 e. Severance



2.Advantage

 a.high quality casting iron

 b. high accuracy double-row short cylindrical roller bearings

 c.manual fine scraping(high precision)

 d.Working table adopts hydrostatic guide way.

 e.the spimdle adopts zwz which got wear resistant

 f.gear was made by quenching way which got little noise



3.Main specification and parameters

Name

Unit

     CK516

Worktable diameter

mm

600

Max. turning diameter of rail head

mm

2000

Max. turning diameter of side head

mm

1800

Max. height of workpiece

                   Mm

                         1250

Max. weight of workpiece

t

8

Max. cutting force of rail head

N

25000

Max. cutting force of side head

N

20000

Total cutting force

N

40000

Max. torque of worktable

N.m

32000

Step num of worktable rotation speed



16 steps

Rotation speed range of worktable

r/min

3.2~100

Cutter head type



Manual penta-angle or Square ram

Feeding amount step num of cutter head



12 steps

Feeding amount range of cutter head

mm/min

0.8~86

Horizontal travel of rail head

mm

1115

Vertical travel of rail head

mm

750

Horizontal travel of side head

mm

600

Vertical travel of side head

mm

900

Rotation angle of rail head

degree

±30°

Quick moving of cutter head

mm /min

1800

Crossbeam travel

mm

890

Lifting speed of crossbeam

mm /min

440

Main motor power

KW

30

Power of crossbeam lifting motor

KW

3.0

Power of cutter head quick speed motor

KW

1.5

Power of cutter head feeding motor

KW

1.3/1.8

Power of oil pump motor

KW

1.5

Machine weight (about)

t

17



4.Charactors:

a. The framework is scrapped by hand which has high geometric accuracy. In order to increase the lubrication oil

 reserve and decrease the friction coefficient.

b. The spindle adopts the world famous brand "ZWZ" with high accuracy double-row short cylindrical roller

bearing take the effect of centering in the process of running or rotating, because radial clearance of bearing

is adjustable; the worktable has higher rotation accuracy.

c. The cutter head device is composed of cutter head slide base and ram. The ram prefer the ductile iron

because of its ability to with stand shock loads, high tensile strength, and abrasive resistance.

d. All gears in adopt harden and grinding processing and have the advantages of stable drive, low noise.

The gears adopt 20 CrMnTi through hardening and grounding.

e. After the process of anneal and turning. The guide rail and worktable scrapped by hand sealed by oil slick

 to make sure that they can run steadily.



5.After-sale Service:

Our promise: Zero distance service

Our goal:No need service

Time:Free charge of guarantee within one year(except wrong operation);

          Paid service for whole lifetime.



6. Main Export Markets:

 Great efficient, high accurate, trouble free, and carefree effects with small investment, our machines sell well in both domestic and overseas markets, we have been exported to to Turkey,Chile, India, USA, Russia and more than 20 countries.

Company Profile

Dalian Wagong Heavy-duty Machine Tool Manufacturing Co., Ltd., a key enterprise of Dalian equipment manufacturing industry, manufactures common, CNC and single/double-column vertical lathes. We boast powerful manufacturing capacity, advanced testing means and strict quality assurance systems. We have been honored as “Dalian Credit AAA Enterprise” Our products are inspected as qualified products by Dalian Institute of Product Quality Supervision & Inspection (JB/T3665.3-2006). Our vertical lathes are chosen to process turbine generator parts for Dongfang Turbine Co., Ltd. and aircraft parts for AVIC Xi’an Aero-Engine Group Ltd.

In the business philosophy of “Credit & Faith”, we win customers with high-quality products and zero-distance after services. Our equipment features small investment, high efficiency, high precision, zero failure and great assurance.
