Quick Details

Place of Origin:
Shanghai China (Mainland)
Brand Name:
Korna
Model Number:
JCV2826GS
Type:
Refrigeration Compressor
Application:
Refrigeration Parts
Certification:
CCC,TUV,UL

Packaging & Delivery

Packaging Detail: 120pcs/pallet, 2880pcs(24 pallets) /20ft container
Delivery Detail: 7-30 days after deposit is received

Product Details

Quick Details

Description

Specifications

small size compressor with seated spring structure,light weight,high reliability,low noise,easy starting at lower voltage

Model Number:JCV2826GS

Displacement:2.8m³

Cooling Type:ST

Motor Type:RSIR

Cooling Capacity:77w

Input Power:77w

COP:1.00w/w

Voltage/ Frequency:220-240V/50Hz

 JCV2826GS R134a-variable speed refrigeration compressorsJCV2826GS R134a-variable speed refrigeration compressorsJCV2826GS R134a-variable speed refrigeration compressorsJCV2826GS R134a-variable speed refrigeration compressors

OTHER MODELS IN THE SAME SERIES

R134a

Series

Model

Displacement

Cooling Type

Motor Type

Cooling capacity

Rated Power

COP



Power Supply



cm3



W

W

W/W

V/Hz

V

JCV20GS

2.0

ST

RSIR

54

54

1.00

220-240/50

JCV25GS

2.5

ST

RSIR

62

62

1.00

220-240/50

JCV2511GS

2.5

ST

RSIR

71

76

0.93

110-120/60

JCV28GS

2.8

ST

RSIR

68

68

1.00

220-240/50

JCV2811GS

2.8

ST

RSIR

77

77

1.00

110-120/60

JCV2826GS

2.8

ST

RSIR

77

77

1.00

220-240/60

JCV35GS

3.5

ST

RSIR

83

89

0.93

220-240/50

JCV3511GS

3.5

ST

RSIR

94

104

0.9

110-120/60

R600a

Series

Model

Displacement

Cooling Type

Motor Type

Cooling capacity

Rated Power

COP



Power Supply



cm3



W

W

W/W

V/Hz

V

JCV33S

3.3

ST

RSIR

49

49

1.00

220-240/50

JCV3311S

3.3

ST

RSIR

59

59

1.00

110-120/60

JCV43S

4.3

ST

RSIR

66

56

1.18

220-240/50
