new automatic paper cup cutting machine

1.ZDM-1 paper cup cutting machine is a automatic roll cutting machine 2. through the iso 9001:2000 quality system & CE Please contact me:naijiaxin11@yeah.net

Product Details

Quick Details

Description

ZDM-1 cutting paper  machine adopts micro-computer control interface, servo positioning ,alternating current frequency converter, automatic counting , manual pneumatic lock plate, photoelectric correcting deviation system,electromagnetic  clutch ,centralized oil lubrication, overload protection  and distinctive gearing. so, it guarantees smooth operations of returning paper and feeding paper , precise positioning and orderly withdrawing . all the key parts and controls of the machine are imported products and finished machining. such installation can realize the machine in steady pressure , precise positioning ,smooth moving, safety and reliability during the machine's operation.


Main technical data
Die cutting precision
+- 0.1mm
Rated die cutting rate
60-----100 (strokes /minute)
Maximum die cutting rate
110 strokes/minute
Maximum die cutting pressure
120t (250 n/cm2)
Maximum die cutting size
900X530 mm
Minimum die cutting size
490X400mm
Applicable paper type
130-----500 g/m2
Various  rolls of paper before or after printing
Total powe of electric machinery
11kw
Power of mainframe
7.5 kw
Overall dimensions (LXWXH)
4000X1700X1700 mm
weight
6000kg
Conditions for using
Draft, dry , 10--25   degree
