• Water Treatment Machine

Water Treatment Machine

The RO system manufactured by us completely adopt the 304 sanitary stainless steel as material,water treatment plant,water plant

Product Details

Quick Details

Description

Specifications

The RO system manufactured by us completely adopt the 304 sanitary stainless steel as material,water treatment plant,water plant

RO system

WTRO series reverse osmosis system possesses the characteristics of high quality,rich experience and reasonable price. Using the international advanced RO membrane, the high efficiency and low noise high pressure pump and correct meter compose and independent reverse osmosis system, so that the whole system unit is on an independent stainless steel support, meanwhile, combines with a clever PLC control system, which can automatically instruct the high pressure pump start or stop and high or low voltage protection, automatically low energy cleaning function.

Reverse osmosis pollution eliminating rate:
1. Desalination rate: >97%
2. Recovery rate: 75%
3. Thermal source eliminating rate: >99%
4. Germ eliminating rate: >97-100%


1. Sand filter: A laminated filter is provided to prevent sand, flocculent and colloid entering into membrane element. Its basic filter element is formed by quartzes sand and anthracite.

2. Active carbon filter: this is provided to absorb organic materials, residual chlorine and other injurants, thus it can reduce the effluent COD and keep SDI under and CL2 under 0.1 mg.l.

3. Softening system: this system is to prevent begrime the membrane by ion of Ca and Me.

4. Precision filter (micro filter) filter of 5um is installed to prevent fine particulate entering the high lift pump and RO membrane.

5. RO system: cut out colloids, bacteria, virus and other impurities, and keep output water conductivity below 5um/cm.

6. Pure water tank: when the pure water tank is full, the RO machine will automatically come to stop, when the pure water tank is empty, the RO system will automatically run to produce the pure water.

Company Profile
