• WS-10000XD1 Automatic high frequency blood bag forming machine

WS-10000XD1 Automatic high frequency blood bag forming machine

WS-10000XD1 Automatic high frequency blood bag forming machine It's special used for disposable blood bags.

Product Details

Quick Details

Description

Model

WS-8000XD1

WS-15000XD1

H.F Power

8KW

15KW

Input Power

13KVA

25KVA

Oscillation

27.12MHZ

27.12MHZ

Voltage

50/60HZ   AC380V

50/60HZ   AC380V

Rectifier

silicon diode

silicon diode

Oscillation tube

7T69RB

8T85RB

Spark tube

NL-5557

NL-5557

Press way

pneumatic

pneumatic

pneumatic

7kg/cm2

7kg/cm2

Max.Pressure

1200kg

2000kg

Feeding system

Servo motor drawing sheet feeding

Servo motor drawing sheet feeding

Max giving material distance

600mm

600mm

Gap of electrode

150mm

150mm

Working distance

150mm

150mm

Up board size

300×650mm

300×650mm

Working plate

400×750mm

400×750mm

Put tube way

manual/automatic

manual/automatic

Capacity

500-600pieces/hour

800pieces/hour

Processor

PLC touch screen

PLC touch screen

Machine Size

8200×1800×1700mm

8200×1800×1700mm

Weight

2800kg

3200kg


WS-10000XD1 Automatic high frequency blood bag forming machine
It's special used for disposable blood bags.

blood bag machine

Company Profile

Suzhou Rijin Machine Co., Ltd.  Adopt Japanese diagram and Japanese electronics technology professional production of various kinds of high frequency welding machines, ultrasonic plastic welding machines, thermoforming machines, dedicated to plastic packaging, plastic welding, medical bag making, vacuum forming machine the R&D, manufacturing and sales. Guangdong factory department in following Guangshen high way from five minutes, the shenzhen airport 20 minutes drive, traffic is convenient, Suzhou factory located in suzhou high-tech zone with developed economy. Our company have R&D department, technology department, Marketing Department, in coastal cities and the after-sale service department pit.

Our main products:
High frequency welding machines and urine bag/blood bag/infusion bag machines
Ultrasonic plastic welding machines
Vacuum forming, clamshell packaging equipment
Electronic pulsed welding equipment

Our company take "the good faith first, quality foremost, development and innovation" for the purpose, welcome all customers to come to consult, order all kinds of equipments, we will be good quality, reasonable price, perfect after-sales service, warm loyal cooperate with both old and new customers. Omni-directional meets the customer need, is "Rijin" eternal pursuit.
