  • QDJ Tire Cutter

QDJ Tire Cutter

The QDJ TireCutter is used to cut all kinds of tires, including steel tire, fiber tires. The tires need to be debeaded before cut into different size of rubber blocks. It mainly consists of motor, rotating platform, rolling shelf, fixed blade shelf, cutting blade shelf, body frame, cylinder, hydraulic station and control cabinet, etc.

Product Details

Quick Details Parameter

Capacity (pcs/H): : 10-30
Handling tire (mm): : < =1000
Motor power (kw): : 5.5
Working pressure(MPa): : 8
Weight (T): : 1.8

Description

The QDJ Tire Cutter is used to cut all kinds of tires, including steel tire, fiber tires. The tires need to be debeaded before cut into different size of rubber blocks. It mainly consists of motor, rotating platform, rolling shelf, fixed blade shelf, cutting blade shelf, body frame, cylinder, hydraulic station and control cabinet, etc.
Structure and Principle
The blades are made of high quality imported materials, wear-proof, heavy-duty and long life;
The rolling shelf and rotary platform make the operation easy and quick;
Automatic reposition function after each cut;
With blocking Pole to avoid tires sticking
The hydraulic system adopts international advanced constant power variable plunger pump technology, low noise, and high pressure and improved the stability and life of the machine.
