Size(L×W×H)(mm)： : 5200*2400*2600
Power: : 25 KW
Motive Power: : 2HP+2HP (computer VVVF)
Change Color Standard: : 160*1700 MM
Working width: : 1650 mm (65
Working speed: : 0-35 m/min
1,It uses the oven and the fan to dry the products with stainless steel cooling type electrothermal tube.
2,To make it simply, it uses the computer to control the two powers in the front part and the back part at the same time, and the speed of the frequency control of the motor will keep together.
3,high speed auto cutting and receiving in unwinding,rewinding,no stop
4,machine tension four float roll seven motor sychronous control in closed loop
5,steady tension when speed is changing,high yield
6,air cooling device
7,high definition inspection unit and high actually register system
8,delux and novel surface design
9,Taida frequency converter control vector motor
10, low friction cylinder control float roll tension
1. The machine surface should be without watermarks, oil, dust, debris, large drum, mesh belt, rolling wheels, idler pulley, plastic pots, plastic roller, pulp wheel, knife plate should wipe, wash clean.
2. Strictly prohibited on-load open, barrier gate.
3. Motor can never exceed the load; accelerate, deceleration turning "speed adjustment" knob should be careful, and gradually transferred to the required speed, or easily damaged motor.
4. Forbid to operate "positive inversion switch" when machinery is in running, otherwise fragile to damage converter and motor.
5. To adjust the wheel of stepless variable speed machine can fine-tune the tightness of printing when machine running, keep material speed synchronous with the print roller, but prohibit to rotate the hand wheel when machine stop, (that is to say can not change speed), Otherwise, easy to damage stepless gearbox.
6. Keep waxing regularly on stepless gearbox, motor belts, often add oil in chains, bearings, cylinder stroke, and change oil regularly in worm gear reducer to ensure its lubrication, running well.
7. Under normal circumstances, "Manual / Auto" switch of electrical panel box should be at "automatic" position, electric eyes, limit switch works..
8. Inverters data has been set well before leaving the factory, non-professionals is strictly prohibited to change, set, disassembly and repair.
