Pit type tempering furnace

Pit type tempering furnace can also be used for mechanical parts for tempering ,annealing, normalizing, carburizing and carbonitriding heat treatment, etc, electricity or gas can be used for heating, with electricity as heat source, is called the pit type resistance furnace,can form a complete set of heat treatment production line with pit type tempering furnace, quenching tank, washing machine and other equipment.

Product Details

Quick Details

Description

Brief

RJ2 series pit type tempering furnace is batch type heat treatment furnace, tempering temperature is 650℃, using the high or low temperature tempering after quenching in a relatively sealing state cavity. Pit type furnace is usually placed under the ground plane in the workshop, also is placed above the ground plane, or ground level fluctuation in each half.


Application field

Mainly used to rod, long axis, plate, shaft and other metal materials and mechanical parts.


Structure

Pit type tempering furnace is mainly composed of furnace shell, lining, heating device, muffle tank , loading frame,.furnace cover and hoisting mechanism of furnace roof.


Advantages

Furnace body is cylindrical deep well, workpiece is installed vertically furnace inside for heating, not easy to deformation.


Pit type tempering furnace can also be used for mechanical parts for tempering ,annealing, normalizing, carburizing and carbonitriding heat treatment, etc, electricity or gas can be used for heating, with electricity as heat source, is called the pit type resistance furnace,can form a complete set of heat treatment production line with pit type tempering furnace, quenching tank, washing machine and other equipment.


Main technical parameters

Model

Rated power

(KW)

Rated temperature

(℃)

Rated voltage

(V)

Phase

Furnace hearth

size(mm)

Max loading

Capacity(kg)

Weight

(kg)

RJ2-25-6

25

650

380

3

ф400*500

150

1100

RJ2-35-6

35

650

380

3

ф500*650

250

1300

RJ2-55-6

55

650

380

3

ф700*900

750

2100





Pit type tempering furnace

Company Profile

Established in 2003, Located in Yanjin County of Henan Province in China, Xinxiang Zhongli Furnace Industry Co., Ltd is a professional manufacturer of heat treatment furnace. After over 10 years' development, ,now covers an area of 38000 square meters, with staff 300 people, including professional design personnel 30 people, 5 senior engineers. Formed the annual output of over 1000 industrial furnace production ability. The main products include bogie hearth furnace, pit furnace, box type furnace, mesh belt furnace, push type furnace and various heat treatment production line, mainly used for various workpiece and mechanical parts for quenching, tempering, annealing, normalizing and carburizing heat treatment.etc,
In order to meet customers' requirements much better, various size furnace can be designed and manufactured according to user's needs, we sincerely hope for the friends at home and abroad come to visit our factory.
