• Pail-typed Advanced Milking Machine

Pail-typed Advanced Milking Machine

YT-I and YT-II Please contact us:wangyuhua0321@163.com

Product Details

Quick Details

Description

  Pail-typed advanced milking machine is a more extensive way of milking. According to the number of barrels used, Vacuum Pump-typed Advanced Mobile Milking Machine can be divided into two categories, they are Single-barrel Type (Type YT-I) and Double-barrel Type (Type YT-II).Because this approach is limited by space, and the scaffolding system is relatively simple. Moreover ,its simple supporting facilities are easy for operation ,scale is moderate and has good scalability, It has advantage of being used within a wide range, so it is deeply popular with various users.


 Main Performance and Technology Parameters

Item model

YT-I

YT-II

Operation Vacuum Degree

0.04-0.05 MPa(adjustable)

0.04-0.05 MPa(adjustable)

Pulsation Times

60-80 times per minute

60-80 times per minute

Pulsation Rate

60/40

60/40

Power Fitted

0.75KW

1.1KW

Voltage

220V or 380V

220V or 380V

Motor Speed

1440 rpm per minute

1440 rpm per minute

The Number of Milking Cattle Per Hour

12-14 cows per hour

24-28 cows per hour

The Number of Stainless Steel Milk Bucket

One(capacity of 25kg)

Two (each of capacity of 25kg)

Employees Needed When Milking

one

One

Vacuum Pump Capacity(L/min)

200/250

200/250

The Number of Milking Cup Group

One set

Two sets
















Company Profile

Zibo lukin machinery factory is a collection of livestock machinery production, management, sales for the integration of comprehensive factories, has the rich production experience and strong technical force, reliable test method, advanced technology and equipment, and that the quality of the products more reliable, from the customer high praise, products are sold throughout the country, our factory is specialized in the production and business operation stainless steel milk barrels, imported transparent milk barrels, milk cup piston milking machine, vacuum pump type milking machine, set milk ware, measuring bottle, pipe bucket type milking machine, herringbone type milking hall, herringbone paratactic type milking hall design and installation, and sales of transparent tube, various parts of rubber inside. The adhering to the "customer is god" business philosophy, with first-class technology, perfect after-sales service, lets users worry-free.

    Adhere to the quality strives for the survival, to the prestige strives for the development, the most outstanding products, the most preferential price, the most efficient service, from all walks of life friend, altogether will create magnificently!
