• PM  Stepper Motor-15BY45

PM Stepper Motor-15BY45

Application:Thermal Printer Monitoring Equipment Please contact us:hexiaojing523@126.com

Product Details

Quick Details

Description



Model


Rated Voltage
(V)

Coil Resistance

Insulation Resistance
MΩS

Dielectric
Strength

Step
Angle

Drive
Method

Drive
Circuit

Insulation
Grade

15BY45

5

12

100

AC500V 1S

 18°

2-2phase

Bipolar

CLASS E



15BY45

7.2

30

100

AC500V 1S

18°

2-2phase

Bipolar

CLASS E








Company Profile


  Changzhou Leshi Leili Motor Co.,Ltd, predecessor company Changzhou Leili Electrical Equipment Co.Ltd. Established in 1993, our products including BY series PM stepping motor,BYJ series Speed-down stepping motor,BYG series hybrid stepping motor,DC series brushed, BLDC series brushless motor, SM series synchronous motor, HM series hysteresis synchronous motor, Q series drain motor and BPX series upper drain pump.Moreover,Plastic injection parts, Stamping parts,gear and tooling such high precision components are available. Our products application industries including:Home-appliance,HVAC,OA,CCTV monitoring system, Intelligence sanitary ware and vehicle control system.
  With its group management and 6subsidiaries company.Plant area more than 140000 square meters. Fixed assets more than 200million yuan,3000employee.Annual production capabilities more than 15million units. We are ISO9001 and ISO14001 certificated, all the products bear RoHS mark.2subsidiaries of plastic injection plant and stamping plant get TS16949 certification. Relevant motor get CCC,UL,VDE,CE,CB certification.
  Taking the advantages of product development and component manufacturing.We provide kinds of superior quality and competitive micro motors and relevant solution. During the cooperation with 20units of The world top 500 enterprise,Leili motor get the market recognition and honor.
  In 2011, we are launching a landmark work for stock exchange listing, to achieve development by leaps and bounds and be a leading micro motor manufacturer and a solution expert for control system.
