• Multifunctional Dispersing Kettle

Multifunctional Dispersing Kettle

FS series multifunctional dispersing kettles are integrations of powerful agitator and high speed disperser, which are applicable for agitation, dispersion, dissolution and color mixing of medium/high viscous and thixotropy materials.

Product Details

Quick Details

Description

FS series multifunctional dispersing kettles are integrations of powerful agitator and high speed disperser, which are applicable for agitation, dispersion, dissolution and color mixing of medium/high viscous and thixotropy materials. Agitation and dispersion can proceed simultaneously and realize ideal effect. They are ideal agitating and dispersing equipment which are easy to operate and widely applicable.


Model

FS-2

FS-3

FS-5

FS-6

FS-8

FS-10

FS-12

Chamber volume(m3)

2

3

5

6

8

10

12

Agitating motor power(KW)

5.5

5.5

7.5

7.5

11

15

18.5

Agitating shaft speed(r.p.m)

50

50

50

50

41

41

41

Agitating blade dia.(mm)

1300

1500

1700

1700

1900

2100

2300

Dispersing motor power(KW)

13/16

13/16

22/28

22/28

22/28

26/34

30/42

Dispersing shaft speed(r.p.m)

960/1450

960/1450

960/1450

960/1450

970/1470

970/1470

750/1480

Dispersing shaft quantity

2

2

2

2

2

2

2

External dimension(mm)

D

1400

1600

1800

1800

2000

2200

2400

H

1650

1765

2048

2400

2800

2950

3100

H1

1930

2000

2200

2200

2500

2570

2620



Multifunctional Dispersing Kettle

Company Profile

Jiangyin Fine Chemical Machinery Co., Ltd. has been dedicated in R&D of agitators, dispersers, bead mills, mixing kettles and bag filters since 1970s. Our products are widely used in such industries as paint, dye, printing ink, pesticide, papermaking and adhesive. We have produced the largest paint mixing kettle in China and vertical bead mills which represent the world leading technology. In 2006, Jiangyin Fine Chemical Machinery Co., Ltd. set up a joint venture Jiangyin Microtron Machinery Co., Ltd. with Cheshire Dispersion Co., Ltd.(UK).

Microtron vertical bead mill was listed in the top 10 inventions of UK in 2006, which has been recognized as the highest efficient grinding equipment. We have become the largest specialized company and our turnover has been steadily occupying the top position in this business line in China. Our rich expertise, reliable product quality, precise machining and considerate service will ensure you a satisfactory solution.
