  • LTP YC Series AC Motor 5.5Kw

LTP YC Series AC Motor 5.5Kw

1) 2 year warranty 2) CE, ISO, SONCAP, SGS, etc 3) Free spare parts 4) 100% copper wire and output 5) Fast delivery

Product Details

Quick Details Parameter

Brand Name: : LANDTOP
Model Number: : YC Series
Type: : Asynchronous Motor
Frequency: : 50HZ /60HZ
Output Power: : 0.12kw-7.5kw
Protect Feature: : Totally Enclosed
Phase: : Single-phase
Certification: : CCC,CE,ROHS,UL,VDE,ISO9001
AC Voltage: : 208-230 / 240 V
Place of Origin: : Fujian, China
Efficiency: : IE 1
Product: : YC Series ac motor 3kw
Rated voltage: : 220V
Rated frequency: : 50HZ/60HZ
Protection class: : IP44 or IP54 or IP55
Insulation class: : Class B or Class F
Duty: : Continuous(S1)
Cooling method: : IC0141
Mounting: : B3/B5/B35
Winding: : 100% copper wire
Housing: : Cast iron

Description


LTP YC Series AC Motor 5.5Kw

Application:

YCL series electric motor is used to drive small size machine, especially for household and workshop where only need single phase power supply.

Advantage:

1. Low noise
2. lower temperature raising and starting current
3. higher starting torque
4. reliable operation
5. easy maintenance
6.pretty appearance

Operating Conditions:

1. Protection class: IP44
2. Insulation class: B/F
3. Rated voltage: 220V, 230, 240, 110, 120, 115
4. Cooling type: IC 0141
5. Duty: Continuous(S1)
6. Rated frequency: 50HZ/60HZ

Note:

If you have any special requirements, please contact us.

Technical Data:

Type
Out
put
Voltage
(V)
Current
(A)
Freq.
(Hz)
Power
factor
Eff(%)
Speed

(r/min)
Tstart/Tn
Ist/In
Tmax/Tn
kW
HP
YC90S-2
1.1
1.5
220
7.2
50
0.95
73.2
2880
2.8
6
1.8
YC90L-2
1.5
2
220
8.9
50
0.97
76
2900
2.8
7
1.8
YC100L-2
2.2
3
220
13.2
50
0.96
78.8
2900
3
6.5
1.8
YC90S-4
0.75
1
220
5
50
0.93
73.3
1450
2.8
6.5
1.8
YC90L-4
1.1
1.5
220
7.8
50
0.9
75
1450
2.5
6
1.8
YC100L-4
1.5
2
220
9.3
50
0.92
79.4
1450
2.8
7
1.8
YC112M-4
2.2
3
220
13.6
50
0.9
81.6
1450
2.3
6.5
1.8
YC132S1-4
3
4
220
18.2
50
0.9
83.2
1450
2.1
6.5
1.8
YC132S2-4
3.7
5
220
22
50
0.9
84.9
1450
2.1
6.5
1.8
YC132M1-4
5.5
7.5
220
32.5
50
0.9
85
1460
2
6.5
1.8
YC132M2-4
7.5
10
220
40
50
0.9
85.5
1460
2
6.5
1.8


LTP YC Series AC Motor 5.5Kw

LTP YC Series AC Motor 5.5Kw
