Counts Digital Multimeter Megger Insulation Resistance Meter True RMS AC Voltage Current Temperature Tester

 Large 6600 counts LCD display
Auto range and manual range
True RMS for AC voltage and AC current
Linear frequency measurement for AC voltage and AC current
1KHz low pass filter functions

Product Details

Quick Details

Description

 Features:

Accord IEC61010-1 CAT 1000V

Large 6600 counts LCD display
Auto range and manual range
True RMS for AC voltage and AC current
Linear frequency measurement for AC voltage and AC current
1KHz low pass filter functions
Insulation measurement for 0.01M ohms to 2G ohms
Automatically calculates PI(polarization index) and DAR(dielectric absorption ratio)
Insulation test voltage: 50V/100V/250V/500V/1000V
Temperature measurement: -30 Centigrade to 1300 Centigrades/-22 Fahrenheit to 2372 Fahrenheit
Data logging up to 100 groups



Technical Specifications:
DC voltage: 660mV/6.6V/66V/660V/1000V +- 0.5%
AC voltage: 660mV/6.6V/66V/660V/750V +- 1.5%
DC current: 60mA/400mA +- 1%
AC current: 60mA/400mA +- 1.5%
Resistance: 660ohm/6.6kohm/66kohm/660kohm +- 1.2% 6.6Mohm/66Mohm +- 2%
Capacitance: 6.6nF/66nF/660nF/6.6uF/66uF/660uF/6.6mF/66mF +- 5%
Temperature: -30 C ~ 1000 C +- 1%
Insulation Resistance: Input Voltage (Accuracy)         Range                error
                             50V (0% ~ 20%)               0 ~ 50Mohm            +- 3%
                             100V (0% ~ 20%)              0 ~ 100 Mohm         +- 3%
                             250V (0% ~ 20%)              0 ~ 250 Mohm         +- 3%
                             500V (0% ~ 20%)              0 ~ 500 Mohm          +- 3%
                             1000V (0% ~ 20%)             0 ~ 499 Mohm          +- 3%
                                                                     500 Mohm~2Gohm   +- 5%

Pls note that battery is not included in the package

Package includes:
1 * MS5208 Digital Multimeter with Insulation Tester (with test leads)
1 * User manual
