• Hot air circulation drying oven

Hot air circulation drying oven

Hot air circulation drying oven, after several upgrades, has reached the advanced level .CT series is the first generation product, the average thermal efficiency is about 30%, uses centrifugal fan, chamber circulation outside, manual temperature control. With multiple modification, formed the CT - C oven series, the series all use axial flow fan, with automatic constant temperature control system, and equipped with computer control system for selection.

Product Details

Quick Details

Description



Hot air circulation drying oven, after several upgrades, has reached the advanced level .CT series is the first generation product, the average thermal efficiency is about 30%, uses centrifugal fan, chamber circulation outside, manual temperature control. With multiple modification, formed the CT - C oven series, the series all use axial flow fan, with automatic constant temperature control system, and equipped with computer control system for selection. Thermal efficiency is about 70%, which is the use of steam or electricity for heat source, Heat exchanger with axial flow fan air convective heat transfer of heat, hot air laminar flow through baking tray with material for heat transfer. Fresh air from inlet supplement, waste heat discharged from the humidity outlet, constantly added fresh air and continuously discharging hot and humid air, so to keep relative humidity in the oven. The biggest characteristic of this series is hot air circulates in the cabinet, the entire cycle is closed, so as to enhance heat transfer, saving energy.

Universal drying equipment is widely used in pharmaceutical, chemical, food, light industry, heavy industry and heat curing, drying dehydration of product .Such as: raw material, crude drugs, Herbal Medicine, powder, granule, honey pill size packing bottle, pigment, dyes, dehydration vegetable, dried fruit ,banger, plastic resin, electric elements, drying varnish and so on.

FEATURES

  ▲Wide range of applications, a variety of materials can be dried, is general drying equipment.

  ▲Most of hot air circulate in chamber, high thermal efficiency, energy conservation.

  ▲Use of forced ventilation effect, equips with adjustable air distributing plate, uniform drying, heat source can be steam, oil, electricity, hot water, far infrared, etc.

  ▲Adapt to a wide temperature range, according to user requirements, room temperature ~350 ℃.

▲Low noise, smooth operation, temperature-controlled, easy installation and maintenance.


Hot air circulation drying oven

Company Profile

Company Introduction
Zhengzhou Great Machinery Equipment Co., Ltd As a leading manufacturer and supplier of a variety of microwave drying equipment and heating solutions used in different applications and industries.
We provide all of the resources needed to support industrial microwave and hot air circulation drying equipment and system. Our main products includes microwave vacuum dryer, hot air circulation drying oven, batch dryer, digital displayed constant temperature drying machine,etc.
Our mission is to increase our customers' business productivity while assuring operator safety by helping users realize the maximum benefit from the quality of equipment, human resource, technology
and general processes. This is accomplished in the design and manufacturing of equipment and support components at a level of quality unsurpassed in the industry.

Technical Strengths
With strong technical strengths and a long-term "production, learning, research" cooperation with Xi'an JiaoTong University, Zhejiang University, Zhengzhou University, PLA Information Engineering University, Zhengzhou Institute of Aeronautical Industry Management, Henan University of Traditional Chinese Medicine, Zhengzhou University of Light Industry and other famous universities, thus all the machines from our company enjoys good reputation in both technology and quality. With the cooperation with some famous companies in China, such as Beijing Tongrentang Co.,ltd( famous medicine company in China), NI's INT( rose drying company) which invest more than 20million RMB, makes our company more famous and help us to take our technology even better.
