Brief Introduction of tube mill roll :

 The   tube mill roll is mainly used for raw materials and finished products of cement grinding, also used in metallurgy, chemical, electric power, industrial and mining enterprises grinding all

kinds of ores and other grinding material. It can be used for open flow grinding, also suitable for close-circuit grinding composed with classifier.

We make significant improvement to the traditional ball mill, besides all advantages of open flow mill, compared with the same specification of ball mill, the mill has the large scale production, and fine powder, and the specific surface area increases. We provide a new type of grinding equipment for the production of high yield, high fine,high standard cement.
The tube mill has adopted special integrate bulkhead and discharge grate to adjust material levels of every chamber so as to increase air ventilation and improve conditions inside; Also used the new liners, adjusted the rotating speed of the grinding machine, the optimization gear design and location of the lubrication parameters, it increases the mill operation stability and service life, and the grinding efficiency increases.

Technical Parameters of tube mill roll :



Sepc.
(Dia. x L)

Rotating
Speed
(r/min)

Inlet
grain
size (mm)

Capacity
(t/h)

Grinder
load
(t)

Main motor

Main reducer

Weight
(t)

Type

Power
(kw)

Rotating
speed(r.p.m)

Type

Speed
ratio

φ2.2×11

20.91

≤25

15~17

50

TR1512-8

570

740

Zd80

5.6

92

φ2.4×8

20.91

≤25

14~18

39.5~42

TRQ1512-8

570

740

Zd80-9

5

76.4

φ2.4×9

20.91

≤25

23~25Closed

50

TR1512-8

570

740

Zd80-9

5

91

φ2.4×10

20.91

≤25

16~22

50

TR1512-8

570

740

Zd80-9

5

111

φ2.4×11

21

≤25

Open 19~24
Closed 22~28

6265

YR710-8/1180

710

740

JDX630

5.6

125

φ2.4×12

21

≤25

Open 18~20
Closed 21~23

6365

YR800-8/1180

800

740

MBY710

6.3

127

φ2.4×13

21

≤25

Open 21~22
Closed 24~26

6668

YR800-8/1180

800

740

MBY710

6.3

131

φ2.6×10

20.6

≤25

21~24

64

YR800-8/1180

800

740

JDX710

6.3

140

φ2.6×13

20.6

≤25

28~31

81

YR1000-8/1180

1000

740

JDX800

6.3

158

φ3.0×9

19.13

≤25

40~45

85

YR1000-8/1180

1000

740

MBY800

7.1

148

φ3×11

18.92

≤25

44~47

95

YR1250-8/1430

1250

740

JDX900

7.1

177

φ3×12

18.92

≤25

48~52

103

YR1250-8/1430

1250

740

JDX900

7.1

182

φ3×13

18.92

≤25

39~45

116max

YR1400-8/1430

1400

740

JDX900

7.1

200.7

φ3.2×11

18.3

≤25

45~48

112max

YR1600-8/1430

1400

740

JDX900

7.15

213.6

φ3.2×13

18.7

≤25

50~55

133max

YR1600-8/1430

1600

740

JDX1000

7.15

237

φ3.4×11

18

≤25

45~55

120max

YR1600-8/1430

1600

740

JDX1000



230

φ3.5×13

17

≤25

60~65

156max

YR2000-8/1730

2000

740

TS130-A-F1



257.6

φ3.8×13
(main bearing)

17

≤25

65~70

190

YR2500-8/1730

2500

740

JS130-C-F1



316

φ3.8×13
(slide shoe edge-driving)

17

≤25

65~70

185

YR2500-8/1730

2500

740

DMG22/2500



313

φ4×13

16.3

≤25

78~80

191

YRKK900-80

2800

745

JS140-A



348

φ4.2×11
(main bearing)

15.8

≤25

100~110

182~190

YR2800-8/17830

2800

740

JS140-A-F1D



350

φ4.2×13
(main bearing)

15.2

≤25

110~120

230

YRKK1000-8

3350

740

MFY355-A



375

φ4.2×13
(main bearing)

15.2

≤25

120~130

245

YRKK1000-8

3350

740

MFY355-A



390

φ4.2×13
(central driving)

15.2

≤25

110~120

230

YRKK1000-8

3350

740

MFY355-A



380

φ4.6×14

15

≤25

100~115

285

YR1000-8

4200

740

J3160-C
